- Private Mold:Yes
- Products Status:Stock
- Ports:10
- Transmission Rate:10/100Mbps
- Function:POE, VLAN Support
- Communication Mode:Full-Duplex & Half-Duplex
- Switch Capacity:2Gbps
- Model Number:TS6208P-2
- Place of Origin:Guangdong, China
- Product Name:PoE switch 8 port
- PoE Standard:IEEE802.3af/at
- PoE Ports:8*10/100Mbps PoE ports
- Uplink Ports:2*10/100Mbps RJ45
- Applications:CCTV Security System
- Power Supply:52V/2.3A 120W
- Management:Unmanaged
- Warranty:1 year
- Certification:CE ROSH FCC
-
- Supply Ability
- 5000 Unit/Units per Month
-
- Packaging Details
ESD bag+kraft paper box+outer carton
-
- Port
Guangzhou,Shenzhen
- Picture Example:
- Lead time:Quantity(pieces)1 – 1011 – 100101 – 500>500Lead time (days)51020To be negotiated
Product Description
10/100Mbps fast Ethernet PoE switch 8 port VLAN 250 meters 48V 120W fanless PoE+ switch for CCTV Camera
Main Features
* 8 ports with PoE,2 port 10/100M RJ45 uplink
* Fully IEEE802.3af/at standard compilant
* Fully IEEE802.3af/at standard compilant
* Support vlan
* Support 250 meters long distance PoE
* Support Max. 30W per port
* Auto detect powered device(PD)
* Safe and reliable power to ech of PoE end device
* Plug&play,no configuration required
* Support Max. 30W per port
* Auto detect powered device(PD)
* Safe and reliable power to ech of PoE end device
* Plug&play,no configuration required
Specification
|
Product name
|
8+2 Port Long Range 250 meters PoE Switch
|
|
Interface
|
8*10/100Mbps LAN PoE ports
2*10/100Mbps RJ45 uplink ports
|
|
PoE standard
|
IEEE802.3af / IEEE802.3at
|
|
Power supply
|
52V/2.3A
120W
|
|
Transmission mode
|
Store and forward
|
|
Transmission rate
|
10/100Mbps
|
|
Transmission distance
|
Maximum 250 meters
|
|
Bandwidth
|
2G
|
|
Max address table
|
2K
|
|
Network medium
|
10/100BASE-TX:5 class and above non shielded twisted pai
|
|
Environment
|
Working temperature : 0℃~50℃
Storage temperature : -40℃~70℃
Operating humidity : 10%~90% Non coagulation
Storage humidity : 5%~95% Non coagulation
|
|
LED indicator
|
LINK/ACT.100Mbps;POE Status Indicator; Power indicator;Extender
|
|
Dimension
|
210mm*150mm*32mm
|
|
Weight
|
1.5kg
|
|
Certificate
|
CE (LVD & EMC)
FCC
RoHS
|
|
Warranty
|
1 year
|
Detailed Images
