Features
Low Insertion Loss, High Return Loss
Good Repeatability and Interchangeability
Applications
Long-haul, Metro and Access System
Fiber CATV and Fiber Network System
Specifications:
|
Parameters |
|
|||
|
Connector Type |
SC/UPC-SC/UPC |
|||
|
Fiber Type |
Mult Mode |
Single Mode |
||
|
Insertion Loss |
Max.≤0.2dB |
Max.≤0.3 |
||
|
Return Loss |
≥36dB(no APC connector) |
PC |
UPC |
APC |
|
≥45dB |
≥50dB |
≥60dB |
||
|
Interchangeability |
≤0.2dB |
|||
|
Connection Durability |
≥1000 times |
|||
|
Operating/Storage Temperature |
-40~80ºC |
|||
|
|
50/125µm |
|||
|
Length |
1m, 2m, 3m,Customized |
|||
|
Cover materials |
PVC/LSZH/OFNP |
|||
|
|
single-mode |
|||
|
Wavelength |
1310nm/1490nm/1550nm |
Length tolerance: 0-5M: +5cm/-0cm ; 5-100m:+10cm/-0cm
We also provides a full set of OEM services, such as fiber connector, length, color, fiber grade, specification, material, package etc.
