- Huawei HS8546V5 FTTH is a smart gateway device of Huawei’s Gigabit fiber smart home solution for China Mobile. It provides 1 POTS voice interface, 4 GE/FE adaptive Ethernet ports and dual-band Wi-Fi (2.4GHz & 5GHz), Flexible application, support plug and play, remote diagnosis, green energy saving, and other features.
Huawei HS8546V5 Overview
Huawei HS8546V5 FTTH is an intelligent gateway device manufactured by Huawei for gigabit fibre smart home solutions. It provides a POTS voice interface, four GE/FE adaptive Ethernet ports, and dual-frequency wi-fi (2.4ghz & 5GHz) with a flexible application and supports plug and play, remote diagnosis, green energy saving, and other features.
HS8546V5 supports GPON and EPON technologies to realize ultra-broadband access for home users in FTTH networking scenarios. Its high-performance forwarding capability effectively guarantees voice, data, and high-definition video business experience, and provides FTTH deployment with ideal terminal solutions.Huawei HS8546V5 Specifications
Brand Huawei Model HS8546V5 Working environment Operating temperature: 0ºC to 40ºC Environment humidity: 5% to 95% (noncondensing) Typical power consumption 8 W Power specifications Power adapter input: 100 to 240 V AC, 50–60 Hz System power supply: 11–14 VDC, 2 A WLAN 2.4GHZ: 802.11n 5GHZ: 802.11ac Network-side Port GPON User-side Ports 1 x POTS + 4 x GE + 2.4G/5G Wi-Fi + 1 x USB Indicators POWER/PON/LOS/TEL/LAN/WLAN/WPS/USB Huawei HS8546V5 Features
Flexible application: PC, STB, and other home terminals can be arbitrarily interpolated on the Ethernet port; SIP and H.248 are supported by both protocols, and it is convenient to interface with soft switches.
Plug and Play: Supports remote automatic distribution of voice, broadband, and multicast services through the OMCI protocol and TR069, without on-site configuration.
Remote diagnosis: support POTS port line test, call simulation, PPPoE dial-up simulation, and easy remote fault location.
Green energy saving: It adopts a highly integrated SOC chip, and integrates PON, voice, gateway, and LSW modules on a single chip, saving 25% energy.
| Specification | Huawei HS8546V5 ONU |
|---|
