SKU 1600621976584 Categories ,
  • Model Number:MCUD1
  • Type:OLT
  • Place of Origin:Guangdong, China
  • Brand Name:Huawei
  • Use:FTTH FTTB FTTX Network
  • Warranty Time:1 year
  • Network:POE
  • Supply Ability
    10000 Piece/Pieces per Month
  • Packaging Details

    Retail Carton

  • Port


  • Picture Example:
  • Lead time:Quantity(pieces)1 – 50>50Lead time (days)15To be negotiated
Product Description

Huawei MCUD1 10GE Uplink Card is  MA5608T main control board integrated with 2-port GE and 2-port GE/10GE optical uplink.

Huawei MCUD1 10GE Uplink Card is a mini control unit board. It is the core of the system control and service switching and aggregation. And it can also function as the management and control core of the integrated network management system (NMS). It communicates with service boards about the key management and control information through the master/slave serial port and inband GE/10GE channel. In this manner, the H801MCUD1 board configures, manages, and controls the device, and also implements the simple route protocol functions.

Huawei MCUD GE Control Card is MA5608T main control board integrated with 4-port GE optical uplink.

Huawei MCUD1 10GE Uplink Card is  MA5608T main control board integrated with 2-port GE and 2-port GE/10GE optical uplink.

Product Picture

Product Specification

Items Description
Type The one-fibre bi-directional optical module
Operating Wavelength Tx: 1577 nm
Rx: 1270 nm
Encapsulation Type XFP
Port Rate Tx: 9.95 Gbit/s
Rx: 2.49 Gbit/s
Minimum Output Optical Power 2 dBm
Maximum Output Optical Power 6 dBm
Maximum Receiver Sensitivity -27.5 dBm
Optical Connector Type SC/UPC
Optical Fiber Type Single-mode
Reach 20 km
Overload Optical Power -7 dBm
Extinction Ratio 8.2 dB
Standard ID Description
ITU-T G.987.1 10Gigabit-capable Passive Optical Networks (XG-PON) General Requirements
ITU-T G.987.2 10Gigabit-capable Passive Optical Networks (XG-PON) Physical Media Dependent (PMD) Layer Specification
ITU-T G.987.3 10Gigabit-capable Passive Optical Networks (XG-PON) Transmission Convergence Layer Specification
ITU-T G.988 10Gigabit-capable Passive Optical Networks (XG-PON) ONU Management and Control Interface Specification
Packaging & Shipping

 To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
