brand new huawei OLT MA 5608t Epon Gpon OLT with MCUD

SKU: 1600585077174 Category:
  • Model Number:5608t
  • Type:OLT, OLT
  • Place of Origin:China
  • Brand Name:huawei
  • Use:FTTX
  • Warranty Time:1 year
  • Product name:5608t
  • Ports:16 Ports
  • Warranty:1 Year / 12 Months
  • Keywords:GPON EPON XPON Olt
  • Connector Type:SC LC
  • Function:Fiber Signal Transmission
  • Brand:Huawei Original
  • Dimensions:442*233.5*88mm
  • Package:Carton Box
  • Supply Ability
    1000 Piece/Pieces per Week
  • Packaging Details

    carton Package

  • Port


  • Lead time:Quantity(pieces)1 – 2000>2000Lead time (days)15To be negotiated
Product Description
Model No.
Operating Environment
Temperature: -25℃~+55℃ Humidity:5%~95% (non-condensing)
Temperature: -40℃~+65℃ Humidity:5%~95% (non-condensing)
Temperature: -40℃~+65℃ Humidity:5%~95% (non-condensing)
Power Supply Parameters
-48V DC input Supports dual power protection Working Voltage range -38.4V~-72V
-48V DC input Supports dual power protection Working Voltage range -38.4V~-72V
-48V DC input Supports dual power protection Working Voltage range -38.4V~-72V Support 220V / 110V AC input
Backplane Exchange capacity
Control Board Exchange Capacity
1920 Gbit/s
Access Capacity
128*10G EPON 64*10G GPON 128*EPON 256*GPON 768*GE
48*10G EPON 24*10G GPON 48*EPON 96*GPON 288*GE
16*10G EPON 8*10G GPON 16*EPON 32*GPON 96*GE
Access Type
Upstream interface: 10GE optical, GE optical/electricity Business interface: EPON optical port, GPON optical port, 10G EPON
optical port, P2P FE optical port, P2P GE optical port, Ethernet optical interface
Huawei SmartAX MA5608T OLT is one of telecom operator-class Gigabit Passive Optical Network (GPON/EPON) Optical Line Terminal forlarge-scale aggregation and access networking.
This is the world first OLT which integrates the functionality of the aggregation switch and edge router. It can provide
high-density GPON, 10GPON and Ethernet P2P optical access, triple-play service, TDM/ATM/Ethernet leased line service for business customers & mobile backhaul with high reliability and high precision clock, and high-density GE/10GE interfaces for cascading remote access equipment. HuaweiMA5600T support to simplify network architecture, to improve network reliability and lower TCO essentially
It is usually equipped with GPFD GPBDGPBH service card MCUD1 /MUCD main control card AC or DC power module. ( There are B+ and C+SFP for service card. C+ SFP cover B+ SFP)
