DPU240D-N40A1 Huawei Brand New Power Distribution Unit
The DPU240D-N40A1 Huawei brand new power distribution unit (PDU) engineered to provide reliable, modular, and efficient DC power distribution in telecom networks and data centers. Designed to meet the power management needs of Huawei’s next-gen communication infrastructure, this PDU is an essential component in high-availability, high-density environments requiring -48V DC power supply management.
Key Features
-
Model: DPU240D-N40A1
-
Condition: 100% Brand New, Original Huawei
-
Power Output: -48V DC distribution
-
Rated Capacity: 240A total distribution current
-
Modular Design: Flexible configuration with up to 40 output channels
-
Output Breakers: Configurable current ratings per channel (1A–63A)
-
Monitoring: Intelligent monitoring with real-time current, voltage, and alarms
-
Protection: Overcurrent, short circuit, surge, and grounding protection
-
Installation: 19-inch rack-mountable compact form factor
-
Compliance: Telecom-grade standards for safety and performance
Technical Specifications
| Specification | Details |
|---|---|
| Model | DPU240D-N40A1 |
| Type | -48V DC Power Distribution Unit |
| Input Voltage | -40V to -60V DC |
| Output Channels | Up to 40 output circuits |
| Total Output Capacity | 240A max |
| Output Current per Channel | Configurable (typically 1A–63A breakers) |
| Breaker Type | Plug-in miniature circuit breakers (MCBs) |
| Monitoring Interface | RS485 / CAN / Dry Contact |
| Protection Features | Overload, Short-Circuit, Surge, Polarity Reversal |
| Mounting | 19” Rack-Mount |
| Dimensions | Approx. 3U or 4U (depends on configuration) |
| Operating Temperature | -5°C to +45°C |
| Humidity | 5% to 95% RH, non-condensing |
| Standards Compliance | YD/T 585, CE, RoHS, IEC60950 |
| Warranty | 1–3 Years Manufacturer Warranty |
DPU240D-N40A1 Huawei Applications
-
Telecom Base Stations (Core & Access Layers) – Centralized -48V DC power distribution for RRU/BBU
-
Data Centers & Cloud Nodes – Critical infrastructure power delivery
-
Network Equipment Rooms – Power routing for switches, routers, OLTs, and ODFs
-
Enterprise Server Rooms – Safe and scalable DC power management
-
FTTx Deployments – Supports Huawei MA5800, MA5600, and similar OLTs
Customization & OEM Options
-
Breaker Configuration: Fully customized based on current requirements per channel
-
Alarm Settings: Pre-configured alarm thresholds, SNMP trap support on request
-
Labeling: Private OEM branding with client-specific part numbers
-
Pre-Wired Output Kits: Optional pre-terminated DC cables for fast installation
-
Chassis Finish: Anti-corrosion coated or powder-painted options available for harsh environments
DPU240D-N40A1 Huawei Wholesale & Global Supply Information
-
Authentic Stock: Huawei OEM factory-supplied with full traceability
-
Wholesale Pricing: Discounts for system integrators, carriers, and contractors
-
Safe Export Packaging: Shockproof and anti-static foam-lined packaging
-
Fast Lead Times: Available for rapid deployment and project rollouts
-
Global Shipping: Delivered via air, sea, and express couriers with MSDS/compliance docs
-
After-Sales Support: Technical help, installation manuals, and system configuration support
Why Choose the DPU240D-N40A1 Huawei Power Distribution Unit
-
Reliable -48V DC Distribution with 240A Capacity
-
Flexible 40-Channel Output Configuration
-
Compact, Modular, and Telecom-Grade
-
Intelligent Monitoring & Fault Protection
-
Huawei Quality for Network Uptime Assurance
Request a Quote, Datasheet, or Volume Order Now
Streamline your power infrastructure with the Huawei DPU240D-N40A1 — the trusted choice for carrier-grade DC power distribution.
Contact us today for technical datasheets, project support, and competitive wholesale pricing.
