ETP48200-C2A1 Huawei Brand New 200A Power Converter 4xR4850
The ETP48200-C2A1 Huawei is a high-performance, modular -48V DC 200A power converter, engineered for telecom networks, data centers, and broadband access applications. This system includes 4x R4850 rectifier modules (each delivering 50A), offering a robust and scalable power supply with exceptional energy efficiency. Designed for 19-inch rack mounting, the unit supports real-time monitoring, advanced protection features, and flexible configuration—making it ideal for mission-critical deployments.
Key Features
Model: ETP48200-C2A1
Condition: 100% Brand New, Original Huawei
Output Capacity: 200A at -48V DC
Rectifiers Included: 4x R4850 (50A each)
Smart Control Unit: LCD screen with keypad, alarm indicators
Hot-Swappable Design: Replace rectifiers without powering down
High Efficiency: Up to 96%
Protection Functions: Over-voltage, over-current, short circuit, overheating
Cooling Mechanism: Forced air with intelligent fan speed adjustment
Mounting Type: 19-inch standard rack mount
Certifications: CE, RoHS, IEC60950, YD/T731
Technical Specifications
| Specification | Details |
|---|---|
| Model | ETP48200-C2A1 |
| DC Output Voltage | Adjustable -42V to -58V |
| Maximum Output Current | 200A |
| Rectifier Modules | 4x R4850 (hot-swappable, 50A each) |
| AC Input Voltage | 90V – 290V AC |
| Input Frequency | 45 – 66 Hz |
| Conversion Efficiency | Up to 96% |
| Cooling System | Intelligent fan cooling |
| Monitoring | LCD screen + LED indicators, keypad control |
| Communication Interface | RS232, RS485, optional SNMP/Web GUI |
| Mounting Style | Standard 19-inch rack |
| Operating Temperature | -40°C to +75°C (derating above +45°C) |
| Humidity Range | 5% – 95% RH, non-condensing |
| Dimensions (W × D × H) | Approx. 442mm × 300mm × 220mm |
| Weight | Approx. 26–28 kg (fully loaded with rectifiers) |
| Standards Compliance | CE, RoHS, IEC60950, YD/T731 |
| Warranty | 1–3 Years Manufacturer Warranty |
ETP48200-C2A1 Huawei Applications
-
Telecom Base Stations – Reliable DC power for BBUs, RRUs, and transmission gear
-
Fiber Access Networks – Ideal for powering OLTs, GPON/EPON, and switches
-
Metro & Core Transport Nodes – Powers Huawei OSN, WDM, and SDH systems
-
Data Centers & IT Rooms – Efficient power for routers, firewalls, and core switches
-
Industrial & Utility Sites – Robust power conversion for SCADA, railway, and energy systems
-
Remote or Off-Grid Applications – Compatible with generator/solar hybrid systems
Customization & OEM Options
Custom Branding – OEM labeling with your company logo and model number
Flexible Rectifier Count – Choose 2, 3, or 4 rectifiers per site needs
Preset Output Settings – Custom-configured voltage, current limit, and alarms
Web Monitoring Add-ons – SNMP cards and web-based GUI interfaces available
Harsh Environment Adaptation – Optional rugged enclosures, moisture filters, altitude kits
Extended QA Testing – Extra inspection and soak testing for critical infrastructure
Battery Backup Integration – Optional DCDBs, surge protection, and battery kits
ETP48200-C2A1 Huawei Wholesale & Global Distribution
Bulk Stock Availability – Ready for immediate shipment for large projects
OEM Supply Chain – Direct-from-factory Huawei equipment with full certification
Protective Packaging – Foam-cushioned and anti-static for export safety
Worldwide Shipping – Export-compliant for lithium and telecom-grade goods
MOQ Flexibility – Single-unit or bulk container options available
Expert Support – Integration consulting and remote configuration assistance
Why Choose the ETP48200-C2A1 Huawei Power Converter
-
200A Reliable Output – Supports heavy-load telecom and IT deployments
-
Proven Huawei OEM Quality – Global operator-grade product performance
-
Modular and Serviceable – Hot-swappable rectifiers for fast maintenance
-
Smart & Efficient – High conversion rate reduces operational cost
-
Versatile Application Range – Supports everything from 5G to fiber and industry
Get a Quote or Technical Datasheet Now
Choose the Huawei ETP48200-C2A1 for dependable, energy-efficient -48V DC power delivery—engineered to support next-gen network growth and uptime demands.
Contact us today for competitive pricing, datasheets, and global delivery options!
