ETP48200-C2A4 Huawei Brand New 200A Power Converter
The ETP48200-C2A4 Huawei is a compact, high-reliability -48V DC 200A power converter system, engineered for telecom base stations, data centers, broadband access, and industrial-grade applications. This model supports up to 4x R4850G2 50A rectifier modules, offering modular scalability, smart control, and superior energy efficiency. Designed for 19-inch standard racks, it integrates advanced monitoring and protection systems to ensure maximum network uptime.
Key Features
Model: ETP48200-C2A4
Condition: 100% Brand New, Original Huawei
Output Capacity: 200A @ -48V DC
Rectifier Slots: Supports 4x R4850G2 (50A each)
Hot-Swappable Design: Allows live replacement or upgrade of rectifiers
Smart Monitoring: LCD screen with keypad and alarm indicators
High Power Efficiency: Up to 96%
Intelligent Cooling: Auto fan speed adjustment based on load/temperature
Protection Features: Input/output over-voltage, short circuit, over-temperature
Rack Type: 19-inch standard rack-mount chassis
Compliance Standards: CE, RoHS, IEC60950, YD/T731
Technical Specifications
| Specification | Details |
|---|---|
| Model | ETP48200-C2A4 |
| DC Output Voltage | Adjustable -42V to -58V |
| Maximum Output Current | 200A |
| Rectifiers Supported | 4x R4850G2 (50A each, hot-swappable) |
| AC Input Voltage Range | 90V – 290V AC |
| Frequency | 45Hz – 66Hz |
| Efficiency | Up to 96% |
| Cooling | Forced-air cooling with intelligent fan control |
| Monitoring Interface | LCD + LED indicators, keypad interface |
| Communication Ports | RS232, RS485, optional SNMP/Web GUI |
| Installation Format | 19-inch rack mount |
| Operating Temperature | -40°C to +75°C (derating may apply above 45°C) |
| Humidity | 5% – 95% RH, non-condensing |
| Dimensions (W × D × H) | Approx. 442mm × 300mm × 220mm |
| Weight | Approx. 26–28 kg (including rectifiers) |
| Certifications | CE, RoHS, IEC60950, YD/T731 |
| Warranty | 1–3 Years Manufacturer Warranty |
ETP48200-C2A4 Huawei Applications
-
Telecom Cell Sites – Power source for BBU, RRUs, small cells, and transmission units
-
FTTx & GPON Networks – Ideal for powering optical line terminals and access switches
-
Metro/Core Optical Networks – Stable DC source for Huawei OSN, WDM, and SDH gear
-
Data Center Edge Environments – Supports routers, switches, and PoE systems
-
Industrial/Remote Sites – Suitable for harsh environments in SCADA and automation
-
Hybrid Power Solutions – Compatible with solar/genset integration systems
Customization & OEM Options
Logo Branding & Labels – OEM/private label customization available
Rectifier Configuration – Delivered with 2, 3, or 4 modules based on project needs
Preconfigured Settings – Output voltage, alarm thresholds, and network setup
Advanced Monitoring Add-ons – SNMP modules, WebUI access, external alarms
Chassis Enhancements – Ruggedized enclosure, dust filters, high-altitude adaptation
Extended QA Testing – Tailored for high-reliability or mission-critical applications
Battery Management Options – Add-on DCDBs and battery monitoring features
ETP48200-C2A4 Huawei Wholesale & Global Distribution
Factory Direct Supply – Brand new Huawei OEM systems with full traceability
Bulk Stock Ready – Large volumes available for telecom rollout projects
Export-Ready Packaging – Anti-static and shock-resistant transport packaging
Flexible MOQ – No minimum order quantity for trials or small rollouts
Fast Shipping Worldwide – Certified for international air and sea freight
Tech Support Included – Integration guidance and remote setup consultation
Why Choose the ETP48200-C2A4 Huawei Power Converter
-
200A Modular Output – Power-hungry sites and high-availability infrastructure
-
High-Efficiency Performance – Reduce energy waste and OPEX
-
Huawei OEM Reliability – Trusted by Tier 1 telecom and data operators
-
Scalable Architecture – Upgrade-ready, hot-swappable rectifier modules
-
Built-In Intelligence – Smart display, alarms, and network integration
Contact Us for Pricing, Datasheets & Bulk Orders
Power your mission-critical infrastructure with the Huawei ETP48200-C2A4 — a proven, intelligent, and efficient DC converter for telecom and broadband networks.
Request a quote or datasheet now to start your order or integration plan!
