ETP48200-C4A1 Huawei Brand New Power Converter with 4x R4850G2 Rectifiers
The ETP48200-C4A1 Huawei is a high-performance -48V DC power converter system engineered for telecom networks, broadband infrastructure, and data centers. Equipped with 4x R4850G2 rectifier modules, each rated at 50A, this unit delivers a total output of 200A—making it ideal for dense and high-reliability power environments. Its modular design, high energy efficiency, and intelligent monitoring functions ensure stable and scalable DC power for critical network operations.
Key Features
Model: ETP48200-C4A1 with 4x R4850G2
Condition: 100% Brand New, Original Huawei OEM
Total Output Capacity: 200A @ -48V DC
Rectifier Modules: 4x R4850G2 (50A each, hot-swappable)
High Efficiency: Up to 96% conversion efficiency
Smart Monitoring: Integrated LCD with keypad and LED indicators
Full Protection: Short circuit, over-temperature, overload, and over-voltage
Standard Rack Mount: Compatible with 19-inch and ETSI racks
Cooling System: Intelligent fan-based thermal control
Certifications: CE, RoHS, IEC60950, YD/T731
Technical Specifications
| Specification | Details |
|---|---|
| Model | ETP48200-C4A1 |
| Included Rectifiers | 4x R4850G2 (50A each) |
| Total Output Current | 200A @ -48V DC |
| Output Voltage Range | -42V to -58V DC (adjustable) |
| AC Input Voltage Range | 90–290V AC |
| Input Frequency | 45–66Hz |
| Power Efficiency | Up to 96% |
| Hot-Swappable Modules | Yes |
| Display Interface | LCD screen, keypad, and LED indicators |
| Cooling Type | Forced-air cooling, smart fan speed adjustment |
| Rack Compatibility | 19-inch standard or ETSI racks |
| Operating Temperature | -40°C to +75°C (derated above 45°C) |
| Humidity Range | 5%–95% RH, non-condensing |
| Dimensions (W × D × H) | Approx. 442mm × 300mm × 220mm |
| Weight | Approx. 26–28 kg (with rectifiers installed) |
| Certifications | CE, RoHS, IEC60950, YD/T731 |
| Warranty | 1–3 Years Manufacturer Warranty |
ETP48200-C4A1 Huawei Applications
-
Telecom Base Stations – Reliable power for BBU, RRH, and core site equipment
-
FTTx & ODN Networks – OLTs, DSLAMs, GPON, and switch sites
-
Metro & Core Data Centers – Efficient power for routers, switches, WDM/OTN gear
-
Industrial Communication Sites – Remote telemetry and infrastructure control
-
Outdoor/Remote Environments – Suitable for hybrid solar-diesel or off-grid systems
-
Transport Networks – Ideal for Huawei OSN, SDH, and WDM platforms
Customization & OEM Options
Private Label Branding – Custom logo, serial numbers, and packaging
Power Configuration Options – Scalable setup with 2, 3, or 4 rectifiers
Factory Pre-Settings – Customized voltage, alarm thresholds, SNMP, and IP setup
Extended Accessories – Optional battery monitoring, DCDBs, breakers, and fuses
Advanced Monitoring Options – SNMP (v1/v2/v3), RS232/RS485, web GUI
Environment-Specific Builds – Rugged enclosures and filters for harsh deployment
Extended Testing & QA – Special quality checks for critical infrastructure projects
ETP48200-C4A1 Huawei Wholesale & Global Supply
Bulk Availability – High stock volume for national-level rollouts
OEM-Grade Packaging – Shockproof, anti-static, and export-compliant boxes
Fast Lead Times – Rapid delivery for project-critical deployments
MOQ Flexibility – Single unit, batch orders, or full container loads
Worldwide Export Ready – CE/RoHS-certified for international compliance
Professional Support – Pre-sale consulting and post-sale integration assistance
Why Choose the ETP48200-C4A1 Huawei Power Converter
-
Reliable 200A Power Output – Robust and consistent DC supply
-
Proven Huawei OEM Quality – Trusted by global telecom operators
-
Modular Design – Easy maintenance and scalability
-
Smart Operation – Integrated monitoring and thermal protection
-
Highly Efficient – Up to 96% power conversion, reducing OPEX
Contact Us for Datasheets, Pricing & Volume Orders
Ready to upgrade your telecom power system? The Huawei ETP48200-C4A1 delivers unbeatable performance, efficiency, and reliability for modern networks.
Get in touch now for a personalized quote, technical documents, and bulk supply options!
