ETP48200-C5A2 Huawei Brand New Power Converter with 4x R4850G2 Rectifiers
The ETP48200-C5A2 Huawei is a high-performance -48V DC power converter system featuring 4x R4850G2 rectifier modules, each delivering 50A. With a total output capacity of 200A, this system is ideal for telecom, data center, and broadband network environments. Engineered for efficiency, modularity, and smart monitoring, it provides a reliable and scalable DC power solution in a compact 19-inch rack-mount format.
Key Features
Model: ETP48200-C5A2 with 4x R4850G2
Condition: 100% Brand New, Original Huawei OEM
Rated Output Capacity: 200A @ -48V DC
Rectifier Modules: 4x R4850G2 (Hot-swappable, 50A each)
High Efficiency: Up to 96% conversion efficiency
Intelligent Controller: LCD display with status LEDs and keypad
Full Protection: Over-voltage, over-current, short circuit, and over-temperature
Flexible Integration: Compatible with standard 19-inch racks
Cooling Method: Forced-air intelligent fan control
Certifications: CE, RoHS, IEC60950, YD/T731
Technical Specifications
| Specification | Details |
|---|---|
| Model | ETP48200-C5A2 |
| Rectifiers Included | 4x R4850G2 (50A per module) |
| Total Output Capacity | 200A @ -48V DC |
| Output Voltage Range | -42V to -58V DC (adjustable) |
| AC Input Voltage Range | 90–290V AC |
| Input Frequency | 45–66Hz |
| Efficiency | Up to 96% |
| Hot-Swappable Modules | Yes |
| Monitoring Interface | LCD display with keypad and LED indicators |
| Cooling System | Forced-air cooling with smart fan control |
| Rack Compatibility | 19-inch or ETSI standard rack |
| Operating Temperature | -40°C to +75°C (derating above 45°C) |
| Relative Humidity | 5% to 95% RH, non-condensing |
| Dimensions (W × D × H) | Approx. 442mm × 300mm × 220mm |
| Weight | Approx. 26–28 kg (with rectifiers installed) |
| Compliance & Safety | CE, RoHS, IEC60950, YD/T731 |
| Warranty | 1–3 Years Manufacturer Warranty |
ETP48200-C5A2 Huawei Applications
-
Telecom Base Stations — Reliable DC supply for 4G/5G BTS and access nodes
-
Broadband Networks — OLT, DSLAM, GPON, and other FTTx equipment support
-
Data Centers — Provides power to switches, routers, and backup systems
-
Optical Transport Networks — Perfect for Huawei OSN, WDM, and SDH platforms
-
Industrial & Utility Infrastructure — SCADA, substations, remote monitoring units
-
Solar + Hybrid Sites — Used in hybrid solar-genset telecom setups
Customization & OEM Options
Private Branding – Custom logo, part number labeling, and packaging
Configurable Rectifier Count – Order with 2, 3, or 4 rectifiers based on power needs
Preconfigured Settings – Voltage presets, SNMP IP config, alarms & user roles
Accessory Packages – Power cables, fuse panels, battery connectors, mounting kits
Remote Monitoring Interfaces – SNMP v1/v2/v3, RS232, RS485, and WebUI options
Silent Mode Versions – Optional reduced-noise systems for indoor deployments
Enhanced Testing Services – Extended burn-in or environmental stress tests for harsh sites
ETP48200-C5A2 Huawei Wholesale & Global Supply
Bulk Stock Availability – Ideal for integrators, ISPs, and national rollouts
OEM Packaging – Secure, anti-static, export-ready packaging
Rapid Delivery – Available with short lead times and priority shipping
Flexible Order Quantities – Single unit or container-load purchases welcome
International Compliance – Fully certified for cross-border telecom deployment
Dedicated Support – Integration consultation and technical support on request
Why Choose the ETP48200-C5A2 Huawei Power Converter
-
Reliable 200A Output — Stable and efficient DC power for mission-critical networks
-
Huawei OEM Standard — Quality you can trust for carrier-grade deployments
-
Smart & Modular — Easy to monitor, maintain, and scale
-
Energy Saving — Up to 96% efficiency for reduced OPEX
-
Flexible Deployment — Racks easily in telecom and enterprise environments
Contact Us Today for Pricing, Datasheets & Volume Orders
Upgrade your power infrastructure with the Huawei ETP48200-C5A2 — the trusted, intelligent power converter for telecom and data networks worldwide.
Message us now for live stock updates, technical datasheets, or a custom quote.
