ETP48200-C5A4 Huawei Brand New Power Converter with 4x R4850G2 Rectifiers
The ETP48200-C5A4 Huawei is a high-efficiency, -48V DC power converter system built to power telecom, enterprise, and broadband network infrastructure. Featuring 4x R4850G2 rectifiers, each rated at 50A, it delivers a total output capacity of 200A. With intelligent monitoring, modular expandability, and hot-swappable rectifiers, this converter ensures reliability and ease of maintenance in mission-critical environments.
Key Features
Model: ETP48200-C5A4 with 4x R4850G2
Condition: 100% Brand New, Genuine Huawei OEM
Total Output Capacity: 200A @ -48V DC
Rectifier Modules: 4x R4850G2 (50A each)
Input Voltage Range: 90–290V AC
Conversion Efficiency: Up to 96%
Monitoring Interface: Smart controller with LCD & LED indicators
Protection Functions: Over-voltage, over-current, short circuit, over-temp
Hot-Swappable Modules: Supports online maintenance and expansion
Mounting Format: Standard 19-inch rack-mount compatible
Cooling System: Intelligent fan-cooled
Certifications: CE, RoHS, IEC60950, YD/T731
Technical Specifications
| Specification | Details |
|---|---|
| Model | ETP48200-C5A4 |
| Rectifiers Included | 4x R4850G2 (50A each) |
| Total Output Current | 200A @ -48V DC |
| Output Voltage Range | -42V to -58V DC (adjustable) |
| AC Input Range | 90–290V AC |
| Input Frequency | 45–66Hz |
| Efficiency | Up to 96% |
| Hot-Swappable Rectifiers | Yes |
| Display | LCD controller with keypad and status LEDs |
| Cooling | Intelligent forced-air fan |
| Rack Compatibility | 19-inch or ETSI standard rack |
| Operating Temperature | -40°C to +75°C (derating above 45°C) |
| Humidity | 5%–95% RH, non-condensing |
| Dimensions (W x D x H) | Approx. 442mm × 300mm × 220mm |
| Weight | Approx. 26–28 kg with rectifiers |
| Compliance | CE, RoHS, IEC60950, YD/T731 |
| Warranty | 1–3 Years Manufacturer Warranty |
ETP48200-C5A4 Huawei Applications
-
Telecom Base Stations — Reliable DC power for BTS, 3G/4G/5G sites
-
FTTx & Access Networks — Ideal for OLTs, DSLAMs, and GPON systems
-
Data Centers — Stable power for routers, switches, and storage arrays
-
Optical Transport Systems — Compatible with Huawei OSN, WDM, and SDH gear
-
Industrial Automation — Reliable source for control rooms and infrastructure nodes
-
Remote Power Sites — Efficient solution for off-grid or hybrid (solar/genset) installations
Customization & OEM Options
Private Branding – Client logos, part numbers, and labeling available
Scalable Configurations – Deploy with 2–4 rectifiers based on load requirements
Preloaded Settings – Voltage thresholds, SNMP parameters, alarms pre-configured
Full Accessory Kits – Breaker panels, surge protectors, power cables, and connectors
Remote Monitoring Integration – SNMP, RS232, RS485, WebUI, and dry contacts
Low-Noise Variants – Optional noise-reduced versions for indoor use
Quality Testing Services – Optional burn-in and temperature stress testing
ETP48200-C5A4 Huawei Wholesale & Global Supply
Bulk Inventory – Ideal for telecom rollouts and infrastructure builds
OEM Packaging – Export-ready, anti-static, and impact-resistant packaging
Fast Shipping – Quick delivery for urgent deployment timelines
MOQ Flexibility – From single-unit orders to full-scale project procurement
International Compliance – Fully certified for global distribution
Support Included – Integration documentation, setup assistance, and remote support
Why Choose the ETP48200-C5A4 Huawei Power Converter
-
High-Capacity Output (200A) — Powers diverse telecom and enterprise equipment
-
Huawei OEM Quality — Trusted performance in carrier-grade deployments
-
Modular & Smart — Intelligent monitoring with hot-swap maintenance
-
Flexible Integration — Rack-mount ready, SNMP-enabled, highly configurable
-
Energy Efficient — Reduces operational costs through high conversion rates
Contact Us Today for Datasheets, Pricing & Bulk Inquiries
Power your mission-critical operations with the Huawei ETP48200-C5A4 — the dependable DC converter solution trusted by telecoms and data centers worldwide.
Reach out now for tailored quotes, configuration support, or wholesale partnership opportunities.
