ETP48200-C5A7 Huawei Brand New Power Converter with 4x R4850G2 Rectifiers
The ETP48200-C5A7 Huawei is a robust and high-efficiency -48V DC power converter system equipped with 4x R4850G2 rectifiers, each delivering 50A, for a total output capacity of 200A. Designed for telecom networks, broadband infrastructure, and data center environments, this intelligent power system supports modular expansion, remote monitoring, and real-time system diagnostics. Its compact rack-mount design ensures quick deployment and integration in both indoor and outdoor cabinets.
Key Features
Model: ETP48200-C5A7 with 4x R4850G2
Condition: 100% Brand New, Genuine Huawei OEM
Rated Output: 200A @ -48V DC
Rectifier Modules: 4x R4850G2 (50A each)
High-Efficiency Operation: Up to 96% power conversion efficiency
Smart Controller: Integrated LCD screen for monitoring and control
Protection Functions: Over-voltage, overload, short circuit, and over-temperature
Hot-Swappable Rectifiers: Zero-interruption maintenance and expansion
Rack Standard: Compatible with 19-inch and ETSI telecom racks
Cooling System: Forced-air intelligent fan cooling
Certifications: CE, RoHS, IEC60950, YD/T731
Technical Specifications
| Specification | Details |
|---|---|
| Model | ETP48200-C5A7 |
| Rectifier Modules | 4x R4850G2 (50A per module) |
| Total Output Current | 200A @ -48V DC |
| Output Voltage Range | -42V to -58V DC (adjustable) |
| AC Input Voltage | 90–290V AC |
| Input Frequency | 45–66Hz |
| Power Conversion Efficiency | Up to 96% |
| Hot-Swappable Rectifiers | Yes |
| Controller Interface | LCD display with keypad and status LEDs |
| Cooling Method | Forced-air fan cooling |
| Mounting Compatibility | 19-inch rack or ETSI cabinet |
| Operating Temperature | -40°C to +75°C (derating may apply above 45°C) |
| Relative Humidity | 5%–95% RH, non-condensing |
| Dimensions (W x D x H) | Approx. 442mm × 300mm × 220mm |
| Weight | Approx. 26–28 kg with rectifiers |
| Compliance & Safety | CE, RoHS, IEC60950, YD/T731 |
| Warranty | 1–3 Years Manufacturer Warranty |
ETP48200-C5A7 Huawei Applications
-
Telecommunication Networks — Provides DC power to base stations, BTS, and 5G sites
-
Broadband Access Equipment — Reliable supply for GPON, OLT, DSLAM systems
-
Data Centers — Ideal for powering switches, routers, servers, and storage nodes
-
Optical Transport Networks — Compatible with Huawei OSN, WDM, and SDH platforms
-
Industrial Infrastructure — SCADA systems, substations, and monitoring devices
-
Backup & Hybrid Power Systems — Suitable for solar + generator hybrid power sites
Customization & OEM Options
Brand Customization – Apply custom logo, part numbers, and client-specific markings
Flexible Rectifier Count – Deploy with 2, 3, or 4 rectifiers per site load requirements
Factory Pre-Configuration – Alarm thresholds, SNMP setup, and communication presets
Accessory Bundles – DC distribution panels, surge protection, load fuses, and wiring kits
Advanced Monitoring Integration – SNMP, RS232, RS485, and WebUI support
Silent Operation Mode – Optional low-noise variants for sensitive indoor environments
Quality Control Enhancements – Extended burn-in and testing for mission-critical sites
ETP48200-C5A7 Huawei Wholesale & Global Distribution
Bulk Availability – Ready inventory for telcos, ISPs, and OEM partners
Export-Ready Packaging – Anti-static, foam-padded OEM boxes for global transport
Rapid Shipping – Short lead times and express dispatch for urgent deployments
Flexible MOQ – From single units to large project orders and containers
Worldwide Compliance – Conforms to international safety and telecom standards
Technical Assistance – Pre- and post-sale configuration support and manuals
Why Choose the ETP48200-C5A7 Huawei Power Converter
-
200A High Power Output — Suitable for large-scale network infrastructures
-
Huawei OEM Quality — Trusted for global telecom-grade performance
-
Hot-Swappable Rectifiers — Maintenance without downtime
-
Smart Monitoring & Control — Enhanced visibility into power conditions
-
Space-Efficient Design — Easily fits into existing rack space
-
Energy Efficient — Reduced electricity costs with up to 96% efficiency
Contact Us Today for Pricing, Datasheets & Bulk Orders
Empower your network infrastructure with the Huawei ETP48200-C5A7 — a proven power supply solution trusted by telecom operators and data centers worldwide.
Message us now for detailed specs, customizations, and global procurement options.
