ETP48200-C5B4 Huawei Brand New Power Converter with 4x R4850G2 Rectifiers
The ETP48200-C5B4 Huawei is a high-efficiency -48V DC power converter system integrated with 4x R4850G2 rectifiers, each rated at 50A. Designed to deliver a total output of 200A, this system is ideal for telecom operators, data centers, and broadband networks requiring stable, scalable, and intelligent DC power supply. Its modular, hot-swappable design ensures maximum uptime, easy maintenance, and long-term reliability in mission-critical environments.
Key Features
Model: ETP48200-C5B4 with 4x R4850G2
Condition: 100% Brand New, Original Huawei
Total Output Capacity: 200A @ -48V DC
Rectifier Modules: 4x R4850G2 (50A each)
AC Input Voltage Range: 90–290V AC
Conversion Efficiency: Up to 96%
Smart LCD Interface: For real-time monitoring, alarms, and logs
Hot-Swappable Rectifiers: Allows online maintenance and upgrades
Comprehensive Protection: Over-voltage, overload, short circuit, over-temp
Mounting Style: 19-inch rack-compatible
Cooling: Intelligent forced-air cooling system
Certification: CE, RoHS, IEC60950, YD/T731
Technical Specifications
| Specification | Details |
|---|---|
| Model | ETP48200-C5B4 |
| Included Rectifiers | 4x R4850G2 (50A per module) |
| Total Output Current | 200A @ -48V DC |
| Output Voltage Range | -42V to -58V DC (adjustable) |
| Input Voltage Range | 90–290V AC |
| Frequency | 45–66Hz |
| Efficiency | Up to 96% |
| Hot-Swappable Rectifiers | Yes |
| Controller Display | LCD screen with menu and LED indicators |
| Cooling Mechanism | Forced-air fan cooling |
| Installation | Standard 19-inch rack |
| Operating Temperature | -40°C to +75°C (derating above 45°C) |
| Relative Humidity | 5%–95% RH, non-condensing |
| Dimensions (W x D x H) | Approx. 442mm × 300mm × 220mm |
| Weight | Approx. 26–28 kg with rectifiers |
| Compliance | CE, RoHS, IEC60950, YD/T731 |
| Warranty | 1–3 Years Manufacturer Warranty |
ETP48200-C5B4 Huawei Applications
-
Telecom Base Stations — Power source for 2G/3G/4G/5G macro and micro sites
-
FTTx & Access Networks — Supports OLTs, DSLAMs, GPON, and broadband systems
-
Data Centers — Powers routers, switches, and storage racks with high reliability
-
Optical Transport Equipment — Compatible with OSN, DWDM, and SDH platforms
-
Industrial Power Systems — Ideal for control centers, monitoring nodes, and automation gear
-
Remote/Backup Sites — Supports solar/generator-based hybrid deployments
Customization & OEM Options
Brand Customization – Logo, model number, and labeling per client requirements
Rectifier Flexibility – Optional 2–4 rectifier deployment based on site load
Pre-Configuration Services – Customized settings for voltage thresholds, alarms, and SNMP
Accessory Bundles – Surge protection, DC breakers, cable harnesses, and busbar kits
Smart Monitoring Integration – RS485, RS232, SNMP & web-based management compatibility
Noise-Control Designs – Silent operation kits for noise-sensitive indoor deployments
High-Availability Testing – Optional extended QA and burn-in for critical infrastructure
ETP48200-C5B4 Huawei Wholesale & Global Supply
Bulk Availability – Ready for nationwide telecom rollouts and large-scale ICT deployment
OEM Packaging – Secure, export-compliant anti-static and shock-proof boxes
Quick Dispatch – Short lead times for fast-track installation projects
Global Logistics – Fully certified for international shipping and compliance
MOQ Flexibility – Support for single-unit orders to container-level procurement
Full Support – Documentation, integration consulting, and after-sales service included
Why Choose the ETP48200-C5B4 Huawei Power Converter
-
200A Total Output – Supports medium to large-scale telecom and IT environments
-
Smart & Efficient – Intelligent monitoring and up to 96% power conversion
-
Hot-Swappable Design – Online maintenance with zero service interruption
-
Huawei OEM Reliability – Backed by years of field-proven performance
-
Customizable & Scalable – Tailored solutions for various network needs
-
Compact Form Factor – Fits seamlessly into 19-inch rack infrastructures
Contact Us Today for Bulk Pricing, Datasheets & Technical Support
Ensure continuous and efficient DC power delivery with the Huawei ETP48200-C5B4 — a trusted power converter solution for modern telecom, data center, and industrial networks.
Get in touch now for full specifications, OEM options, or wholesale offers.
