ETP48200-C5B5 Huawei Brand New Power Converter with 4x R4850G2 Rectifiers
The ETP48200-C5B5 Huawei is a highly reliable and energy-efficient -48V DC power converter system designed for telecom and data center applications. It comes equipped with 4x R4850G2 rectifiers, each delivering 50A, for a total output capacity of 200A. Engineered to support continuous operation in demanding environments, this modular power system features hot-swappable rectifiers, smart controller interface, advanced safety features, and seamless integration into 19-inch standard racks.
Key Features
Model: ETP48200-C5B5 with 4x R4850G2
Condition: 100% Brand New, Original Huawei
Total Output Capacity: 200A @ -48V DC
Rectifiers Included: 4x R4850G2 (50A each)
AC Input Range: 90–290V AC
Conversion Efficiency: Up to 96%
Controller Interface: Integrated LCD with alarms, monitoring, and diagnostics
Protection Features: Over-voltage, overload, over-temp, short-circuit
Hot-Swappable Design: Allows rectifier replacement without power interruption
Mounting: 19-inch rack mountable
Cooling System: Intelligent fan cooling
Compliance Standards: CE, RoHS, IEC/EN60950, YD/T731
Technical Specifications
| Specification | Details |
|---|---|
| Model | ETP48200-C5B5 |
| Rectifiers | 4x R4850G2 (50A each) |
| Total Output Current | 200A @ -48V DC |
| Output Voltage Range | -42V to -58V DC (adjustable) |
| Input Voltage Range | 90–290V AC |
| Input Frequency | 45–66Hz |
| Efficiency | Up to 96% |
| Hot-Swappable | Yes (rectifiers) |
| Controller | LCD display with keypad and LED indicators |
| Cooling Method | Forced-air fan cooling |
| Installation Standard | 19-inch rack |
| Operating Temperature | -40°C to +75°C (derating above 45°C) |
| Relative Humidity | 5%–95% RH, non-condensing |
| Dimensions (W x D x H) | Approx. 442mm × 300mm × 220mm |
| Weight | Approx. 26–28 kg with rectifiers |
| Certifications | CE, RoHS, IEC/EN60950, YD/T731 |
| Warranty | 1–3 Years Manufacturer Warranty |
ETP48200-C5B5 Huawei Applications
-
Telecom Base Stations – Ideal for 2G/3G/4G/5G deployments
-
FTTx & Access Networks – Reliable power for OLTs, DSLAMs, GPON, and MSAN devices
-
Data Centers – Efficient and compact -48V DC power for racks and networking gear
-
Transmission Systems – Supports OSN, DWDM, SDH optical transport platforms
-
Industrial Networks – Robust power source for SCADA, automation, and control systems
-
Backup & Remote Sites – Suitable for hybrid solar/generator deployments
Customization & OEM Options
Custom Labeling – Add your brand name, part number, and company logo
Rectifier Configuration – Deploy with 2, 3, or 4 rectifiers based on site load
Factory Settings – Pre-configured voltage, alarms, SNMP/RS485 communication
Power Kits – Optional DC distribution panels, breakers, surge protectors
Remote Monitoring – Compatible with SNMP/WebUI/RS232/RS485 protocols
Silent Operation Models – Noise-optimized versions for indoor or low-noise environments
Extended QA Options – Burn-in testing and pre-deployment verification
ETP48200-C5B5 Huawei Wholesale & Global Distribution
Bulk Stock Available – Ideal for telecom rollouts, ISPs, and system integrators
Secure Packaging – OEM shock-proof, anti-static, and export-ready cartons
Fast Turnaround – Short lead times for urgent projects and infrastructure upgrades
Global Logistics – Compliant with international transport and customs standards
MOQ Flexibility – Small orders and full container loads supported
Technical Support – Integration assistance, configuration guidance, and full documentation
Why Choose the ETP48200-C5B5 Huawei Power Converter
-
Reliable 200A Power Output – For large-scale telecom and industrial applications
-
High Energy Efficiency (96%) – Lower operational cost and heat generation
-
Hot-Swappable Design – Zero-downtime maintenance and upgrades
-
Smart LCD Controller – Easy monitoring and remote management options
-
Huawei OEM Quality – Trusted performance and durability across global networks
-
Compact Rack-Mount Form Factor – Space-saving and easy integration
Contact Us Now for Datasheets, Pricing & Bulk Orders
Power your network infrastructure confidently with the Huawei ETP48200-C5B5 — a smart, modular, and efficient DC power system trusted by telecom leaders worldwide.
Reach out today for technical specifications, wholesale pricing, or tailored configurations.
