ETP48200-C5D2 Huawei Brand New Power Converter with 4x R4850G2 Rectifiers
The ETP48200-C5D2 Huawei is a compact, high-reliability -48V DC power converter system designed for telecom, data center, and industrial DC power applications. This model includes 4x R4850G2 rectifiers, each delivering 50A output, enabling a total system output capacity of 200A. Featuring Huawei’s intelligent controller, modular design, and high-efficiency rectifiers, this power system ensures stable power delivery, simplified maintenance, and reduced energy loss.
Key Features
Model: ETP48200-C5D2 with 4x R4850G2
Condition: 100% Brand New, Original Huawei
System Output: -48V DC / 200A Total Output
Rectifiers Included: 4x R4850G2 (50A each)
AC Input Range: 90V–290V AC
Conversion Efficiency: Up to 96%
Hot-Swappable Rectifiers: Easy replacement without shutting down the system
Smart Controller: LCD interface for real-time monitoring and configuration
Protection Features: Overvoltage, overload, short circuit, and over-temperature
Cooling System: Variable-speed intelligent fan cooling
Standards Compliance: IEC/EN60950, YD/T, CE, RoHS
Technical Specifications
| Specification | Details |
|---|---|
| Model | ETP48200-C5D2 |
| Included Rectifiers | 4x R4850G2 Rectifiers (50A each) |
| Total Output Capacity | 200A @ -48V DC |
| Input Voltage Range | 90V–290V AC |
| Input Frequency | 45Hz–66Hz |
| Output Voltage Range | 42V–58V DC Adjustable |
| Conversion Efficiency | Up to 96% |
| Mounting Method | 19-inch Rack Mount |
| Controller Display | LCD Display with alarms and control interface |
| Cooling Method | Intelligent Forced Air Cooling |
| Operating Temperature | -40°C to +75°C (derating above 45°C) |
| Relative Humidity | 5%–95% RH, Non-condensing |
| Protection Functions | Input surge, over-temp, short circuit, etc. |
| Compliance Standards | CE, RoHS, IEC/EN60950, YD/T731 |
| Dimensions (W x D x H) | Approx. 442mm x 300mm x 220mm |
| Weight | Approx. 26–28kg |
| Warranty | 1–3 Years Manufacturer Warranty |
ETP48200-C5D2 Huawei Applications
-
Telecom Base Stations – Reliable DC power for BTS, RAN, and transmission equipment
-
Optical Transmission Systems – Supplies OSN, DWDM, SDH, and microwave gear
-
Access Networks – Powers GPON/EPON, DSLAM, and FTTx systems
-
Data Centers – Supports routers, switches, gateways, and security appliances
-
Railway & Industrial Networks – Trusted power for signaling and automation systems
-
Government/Military Communications – Secure, high-availability DC power solutions
Customization & OEM Options
Private Labeling – Custom logo, model number, and corporate branding available
Flexible Rectifier Options – Support for 2, 3, or 4 rectifier configurations
Preset Configurations – Factory pre-configured for voltage, alarms, SNMP settings
Add-On Kits – Fuse panels, battery connections, and AC/DC input kits available
Remote Monitoring – Optional SNMP/WebUI/RS485 for full NMS integration
Noise-Control Fan Kits – Optional silent fan configuration for indoor use
Extended Testing – 48–72 hour burn-in for high-availability deployments
ETP48200-C5D2 Huawei Wholesale & Global Supply
Bulk Inventory Available – Direct from Huawei OEM supply chain
Secure Export Packaging – Anti-static, foam-protected boxes for global shipping
Fast Delivery – Ready stock with short dispatch timelines
Global Distribution – Compliant with international logistics & customs standards
Enterprise Support – Documentation, configuration assistance, and warranty options
Flexible MOQ – Available in small quantities or bulk containers
After-Sales Service – Technical guidance and optional on-site support
Why Choose the ETP48200-C5D2 Huawei Power Converter
-
Efficient 200A DC Output — Optimized for medium-scale telecom and industrial power systems
-
Huawei OEM Performance — Industry-trusted components and long-term reliability
-
Energy-Saving Design — 96% efficiency for lower OPEX and thermal footprint
-
Full Monitoring & Alarms — LCD + remote interface for complete system visibility
-
Modular & Upgradeable — Expandable rectifier slots for future load scaling
-
Rugged Engineering — Operates in extreme environmental conditions
Contact Us Now for Pricing, Datasheets & Bulk Orders
Upgrade your telecom, enterprise, or industrial infrastructure with the Huawei ETP48200-C5D2 — a smart, scalable, and high-efficiency -48V DC power solution trusted by network professionals worldwide.
Reach out today for stock details, customization options, and competitive wholesale pricing!
