ETP48200-C5E2 Huawei Brand New Power Converter with 4x R4850G2 Rectifiers
The ETP48200-C5E2 Huawei is a high-efficiency, compact -48V DC power system equipped with four high-performance R4850G2 rectifiers. Each rectifier provides up to 50A output, resulting in a total power output capacity of 200A, making this system ideal for telecom base stations, broadband access networks, data centers, and industrial applications. Designed for reliability, modularity, and intelligent management, the ETP48200-C5E2 delivers robust power with advanced control and monitoring functions.
Key Features
Model: ETP48200-C5E2 with 4x R4850G2
Condition: 100% Brand New, Original Huawei
System Output: -48V DC / 200A Total Output
Rectifiers Included: 4x R4850G2 (50A each at 48V DC)
Power Input: 90–290V AC Wide Input Range
Conversion Efficiency: Up to 96%
Smart Controller: Integrated monitoring with LCD and remote interface
Modular Design: Hot-swappable rectifiers for flexible capacity management
Protection: Full range of alarms and protections – over-voltage, short circuit, over-temp
Cooling: Intelligent fan control for efficient thermal management
Compliant Standards: CE, RoHS, IEC/EN60950, YD/T
Technical Specifications
| Specification | Details |
|---|---|
| Model | ETP48200-C5E2 |
| Rectifiers | 4x R4850G2 (50A each, 48V DC) |
| Total Output Capacity | 200A @ -48V DC |
| Input Voltage Range | 90V–290V AC |
| Frequency Range | 45Hz–66Hz |
| Output Voltage Range | 42V–58V DC Adjustable |
| Conversion Efficiency | Up to 96% |
| Controller | Integrated Smart Controller with LCD and alarms |
| Cooling | Forced air cooling with intelligent fan control |
| Mounting Type | Standard 19-inch Rack Mount |
| Operating Temperature | -40°C to +75°C (derating may apply above 45°C) |
| Relative Humidity | 5%–95% RH, Non-condensing |
| Compliance | CE, RoHS, IEC/EN60950, YD/T 731 |
| Dimensions (W x D x H) | 442mm x 300mm x 220mm (approx.) |
| Weight | Approx. 26–28kg (with rectifiers installed) |
| Warranty | 1–3 Years Manufacturer Warranty |
ETP48200-C5E2 Huawei Applications
-
Telecom Base Stations — Stable DC power for wireless networks (2G/3G/4G/5G)
-
Broadband Networks — Powers OLTs, DSLAMs, GPON systems, and edge routers
-
Transmission Systems — Reliable supply for SDH, WDM, microwave, and fiber equipment
-
Data Centers — Energy-efficient power for switches, servers, and gateways
-
Industrial & Utility Sites — Provides secure and stable DC backup for mission-critical operations
-
Government & Military Networks — Rugged and reliable power for secure communications
Customization & OEM Options
Private Labeling — Add your company logo or custom model numbers
Flexible Configuration — Choose between 2, 3, or 4 rectifier slots based on power needs
Pre-configured Settings — Voltage output, alarm thresholds, and language set per site specs
Installation Kits — Bundled solutions with fuses, MCBs, battery banks, and cabling
Remote Monitoring Add-ons — Optional SNMP, Modbus, or WebUI support for NOC integration
Extended Burn-In Test — Factory 72-hour full-load testing for mission-critical applications
Fan Customization — Low-noise variants for indoor deployments on request
ETP48200-C5E2 Huawei Wholesale & Global Supply
Direct OEM Access — Original Huawei units at competitive wholesale prices
Bulk Supply Ready — Available from global warehouse hubs for urgent deployment
Professional Packaging — Anti-static, foam-secured boxes for export logistics
Fast Lead Times — 1–5 business days for in-stock orders
Worldwide Shipping — Fully compliant with international freight and customs rules
Tech Support & Manuals — Full documentation and expert guidance available
Warranty Extensions — Optional SLA-based support and warranty upgrades for enterprise clients
Why Choose the ETP48200-C5E2 Huawei Power Converter
-
Scalable 200A DC Power — Ideal for mid-sized telecom and industrial sites
-
High-Efficiency Performance — Up to 96% power conversion reduces OPEX
-
Huawei Reliability — Built with trusted hardware used in global carrier networks
-
Smart Control & Monitoring — Full visibility via LCD and remote options
-
Compact & Modular — Saves rack space and enables easy upgrades or maintenance
-
Comprehensive Protection — Safeguards all connected loads and equipment
Contact Us Now for Pricing, Datasheets & Bulk Orders
Get the power your network demands with the Huawei ETP48200-C5E2 — a reliable, high-efficiency 200A -48V DC power system trusted by telecom operators, ISPs, and industrial clients around the world.
Reach out today for best pricing, stock availability, and OEM options!
