ETP48600-C5A2 Huawei Brand New Power Converter with 9× Rectifiers
The ETP48600-C5A2 Huawei is a high-efficiency embedded power system, engineered to deliver stable -48V DC output with 9 pre-installed rectifier modules, making it an ideal solution for telecom operators, data centers, and large-scale access networks. This brand new, compact, and intelligent power converter ensures reliable energy supply to critical equipment with high power demand.
Key Features
-
Model: ETP48600-C5A2
-
Rectifier Configuration: 9x Rectifier Modules (R4850G or R4875G5, depending on build)
-
Condition: 100% Brand New, Original Huawei
-
Output Capacity: Up to 600A at -48V DC
-
Hot-Swappable Rectifiers: No service interruption during replacement
-
Wide Input Voltage Range: 85V AC to 300V AC
-
Smart Monitoring: Integrated SmartMU controller with remote access
-
High Reliability: Designed for 24/7 critical telecom and data services
-
Efficient Design: ≥96% power conversion efficiency
-
Scalable & Rack-Compatible: Ideal for indoor telecom cabinets and outdoor shelters
Technical Specifications
| Specification | Details |
|---|---|
| System Model | ETP48600-C5A2 |
| Rectifier Model | R4850G / R4875G5 (50A/75A each, depending on config) |
| Number of Rectifiers | 9 pre-installed |
| Total Output Capacity | Up to 600A @ -48V DC |
| Input Voltage Range | 85V – 300V AC (wide range) |
| Output Voltage Range | -42V to -58V DC (adjustable) |
| Efficiency | ≥96% (high-performance energy saving) |
| Monitoring Unit | SmartMU with LCD display, RS232/SNMP support |
| Cooling Method | Forced-air cooling with intelligent fans |
| Mounting Type | Embedded rack/cabinet-mountable |
| Operating Temperature | -40°C to +65°C |
| Humidity Range | 5% to 95% RH non-condensing |
| Alarm Outputs | Dry contact alarms, audible and remote alerts |
| Compliance | IEC60950, CE, RoHS, UL |
ETP48600-C5A2 Huawei Applications
-
Telecom Networks – Powers core routers, base stations, OLTs, and SDH equipment
-
Data Centers – Stable DC power for mission-critical server racks
-
FTTx Infrastructure – Reliable power for ODN and OLT equipment
-
Industrial Installations – Operates in extreme environments with continuous power needs
-
ISP & Cloud Facilities – Ideal for medium-to-large scale internet & hosting infrastructure
Customization & OEM Options
-
Rectifier Mix & Match: Customize with R4850G or R4875G5 based on power needs
-
Pre-Configured Output: Set output voltage levels and alarm parameters in factory
-
OEM Branding: Private labeling for telecom system integrators and resellers
-
Accessory Bundles: Add circuit breakers, battery cabinets, and surge protectors
-
Extended Testing: High-reliability testing available for mission-critical deployments
ETP48600-C5A2 Huawei Wholesale & Global Supply
-
Bulk Order Support: Discounted pricing for volume deployments
-
Global Shipping: Delivered with compliant packaging for lithium power systems
-
Quick Dispatch: Ready stock available in select regions
-
Complete Documentation: Includes user manual, MIB files, and datasheets
-
Integration Support: Available upon request for remote commissioning
Why Choose the ETP48600-C5A2 Huawei Power Converter
9 Rectifiers Included — High-capacity ready-to-deploy power solution
Carrier-Grade Reliability — 99.999% uptime rated hardware
Huawei Original Build — Factory-sealed with full documentation
Energy Efficient — Helps reduce OPEX through high-conversion efficiency
Smart Monitoring Unit — Ideal for remote sites with centralized control
Request Quote, Stock, & Technical Data
Looking for dependable high-capacity power solutions?
The Huawei ETP48600-C5A2 with 9× Rectifier Modules is built to power critical telecom and data infrastructures.
