- Model Number:F660
- Type:ONU
- Place of Origin:China
- Brand Name:ZTE
- Use:FTTX
- Warranty Time:1 year
- Keywords:F660
-
- Supply Ability
- 10000 Piece/Pieces per Month
-
- Packaging Details
Retail Carton
-
- Port
Guangzhou
- Picture Example:
- Lead time:Quantity(pieces)1 – 500>500Lead time (days)15To be negotiated
Product Description
|
Brand
|
ZTE
|
|
Model
|
F660V6.0
|
|
Optical port
|
1 x GPON interface (SC/APC)
|
|
Transmission Distance
|
0-20KM
|
|
Transmit rate
|
2.488Gbps downstream; 1.244Gbps upstream
|
|
User-Network Interface
|
4 x 10/100/1000Base-T
|
|
1 x Wi-Fi interface
|
|
|
1 x USB host interface
|
|
|
2 x POTS interfaces
|
|
|
Wavelength
|
Receiving: 1480~1500 nm Transmitting: 1290~1330 nm
|
|
Receiving Sensitivity
|
-28dBm
|
|
Transmitting Optical Power
|
0.5~5dBm
|
|
Power consumption
|
<10W
|
|
Dimensions
|
220mm(W) x 44mm(H) x 160mm(D)
|
|
Working temperature:
|
0oC ~ 40oC
|
|
Working humidity
|
5% ~ 95%
|
|
Weight
|
380G
|
|
Power supply
|
12V DC
|
ZTE ZXHN F660V6.0 FTTH is GPON optical terminal unit with 1GE + 3FE + 2POTS + WIFI + 1USB ports This model is designed for the FTTH scenario. It supports the L3 function to help the subscriber build a smart home network. It provides subscribers with convenient services, including voice, video (IPTV) and high-speed Internet access
ZXA10 C320 is new-generation compact OLT, only 2U high, saving installation space; high line card density: industry-leading 16-port GPON/EPON and 48-channel P2P board capability, single-frame can provide 32 G/EPON ports and 96 channels P2P GE port; ZTE C320 supports GPON/EPON/P2P/10G EPON/XG-PON1 with the same platform access, and will also support TWDM-PON technology; unified bearer voice, high-speed Internet access, IPTV, traditional TDM and mobile backhaul services. Integrated access; adopts large-scale OLT hardware and software architecture, supports architecture evolution, is compatible with ZXA10 C300 service boards, and saves board costs.
ZXA10 C320 is new-generation compact OLT, only 2U high, saving installation space; high line card density: industry-leading 16-port GPON/EPON and 48-channel P2P board capability, single-frame can provide 32 G/EPON ports and 96 channels P2P GE port; ZTE C320 supports GPON/EPON/P2P/10G EPON/XG-PON1 with the same platform access, and will also support TWDM-PON technology; unified bearer voice, high-speed Internet access, IPTV, traditional TDM and mobile backhaul services. Integrated access; adopts large-scale OLT hardware and software architecture, supports architecture evolution, is compatible with ZXA10 C300 service boards, and saves board costs.
Packing&Shipping
