FTTH modem router wifi GPON EPON ONT WiFi 1GE 3FE USB same function HG8546M onu ont

SKU: 1600117943601 Categories: ,
  • Model Number:HK720
  • Type:Enterprise Router, FTTx Solutions
  • Place of Origin:Guangdong, China
  • Brand Name:HONGKING
  • Dimensions (H x W x D):156 x 125 x 28 mm
  • Gross Weight:210g
  • Ports:1GE+3FE+1POTS+1USB+ WiFi
  • Operating Temperature:0°C to 50°C
  • Operating Humidity:5% RH to 95% RH (non-condensing)
  • System Power Supply:11 V to 14 V DC, 0.5 A
  • Optical Connector:SC/UPC
  • Indicators:Power/PON/LOS/LAN/TEL/USB/WLAN/WPS
  • No. of Fiber:1.
  • Supply Ability
    5000 Piece/Pieces per Week
  • Packaging Details

    Carton box

  • Port


  • Lead time:Quantity(pieces)1 – 2000>2000Lead time (days)5To be negotiated
Products Description

 HK720 same 8546m

HK720 GPON ONT is a new terminal level GPON ONT, which is a variety of FTTB FTTH FTTO accessing ONT published by HUAWEI for

ISPs FTTH network applications. It can support pure data, Data +Voice, Data+ Voice+ WIFI and other service accessing type.
ONT supports standard OMCI, can provide up to 1.25Gbps uplink and 2.5Gbps downlink high-speed transfer rate. It can fully meet
ISPsFTTBFTTHFTTO equipment needs, working with our NGBN unified network management system.

 Product Feature :
* GPON WAN port with 1.244Gbps uplink / 2.488Gbps downlink link speed
*  Active Ethernet WAN port with 1.25Gbps bi-direction link speed
* 1x GE+3FE Ethernet RJ45 Ports
*  2×2 11n WIFI support 300Mbps link speed
*  1x FXS RJ11 ports for Voice service
*  DC 12V adaptor, max 1.5A current
*  -5 to 50℃ operating ambient temperature
Product Overview :
