G-140W-MD GPON Huawei Brand New Terminal OLT Compatible
The G-140W-MD GPON Huawei is a high-performance GPON Optical Network Terminal (ONT) designed for residential and small business users seeking high-speed internet, voice, and wireless services. It supports full compatibility with mainstream OLT platforms, including Huawei’s MA5600/5800 series and third-party GPON OLTs that comply with ITU-T G.984 standards.
This device integrates 1 GE port, 3 FE ports, 1 POTS port, dual-band Wi-Fi (2.4G/5G), and 1 USB port, enabling comprehensive service access including data, VoIP, IPTV, and wireless connectivity in a compact and energy-efficient design.
Key Features
- Model: G-140W-MD
- Brand: Huawei
- Type: GPON Optical Network Terminal (ONT)
- Ports: 1 GE + 3 FE + 1 POTS + 1 USB
- Wi-Fi: Dual-band 2.4GHz & 5GHz
- Voice Support: SIP and H.248 VoIP protocols
- GPON Compliance: ITU-T G.984.x standards
- Security: Firewall, MAC filtering, ACL
- Management: OMCI, Web GUI, TR-069 remote management
- Installation: Wall-mount or desktop
- Compatibility: Fully compatible with Huawei and third-party GPON OLTs
Technical Specifications
| Specification | Details |
|---|---|
| Model | G-140W-MD |
| PON Interface | 1 × GPON (SC/APC, Class B+) |
| Downstream Rate | 2.5 Gbps |
| Upstream Rate | 1.25 Gbps |
| LAN Ports | 1 × GE, 3 × FE |
| Voice Port | 1 × POTS (RJ11), supports SIP & H.248 |
| Wi-Fi | 802.11b/g/n (2.4GHz) + 802.11a/n/ac (5GHz) |
| USB Port | 1 × USB 2.0 |
| Management | OMCI, TR-069, Web GUI |
| Power Supply | DC 12V / 1.5A |
| Power Consumption | < 12W |
| Operating Temperature | 0°C to +40°C |
| Storage Temperature | -40°C to +70°C |
| Dimensions | 220 mm × 160 mm × 30 mm (L × W × H) |
| Mounting | Desktop or Wall-mountable |
| Weight | < 500g |
| LED Indicators | Power, LOS, PON, Internet, LAN, TEL, WLAN |
G-140W-MD GPON Huawei Applications
- FTTH Deployments — Ideal for residential and SOHO fiber-to-the-home networks
- Triple Play Services — Data, voice (VoIP), and IPTV streaming via a single box
- High-Speed Wi-Fi Coverage — Seamless internet access for smart homes
- Multi-Service Access — Internet, telephone, printer sharing, NAS access
- Interoperable Networks — Compatible with most standard GPON OLT vendors
Customization & OEM Options
- Logo & Label Customization — OEM/ODM branding and UI skin support
- Firmware Configuration — Preloaded settings or language packs available
- Packaging — Retail packaging or bulk shipment formats
- Compliance Certification — CE, FCC, and RoHS documentation available
- Extended Temperature Option — For harsh deployment environments
Wholesale & Global Supply Information
- Huawei Original Equipment — Direct-from-source, sealed and certified
- In-Stock Availability — Ready for urgent or bulk deployment orders
- Worldwide Shipping — Secure packaging with fast logistics channels
- Competitive Pricing — Volume discounts for ISPs, integrators, and partners
- Tech Support Team — Assistance for setup, configuration, and OLT pairing
Why Choose the G-140W-MD GPON Huawei
✔ High-Speed Access — Gigabit-ready WAN/LAN interfaces
Dual-Band Wi-Fi — Supports modern smart home wireless demands
Voice Ready — Built-in POTS with SIP and H.248 for VoIP services
Multi-OLT Compatibility — Seamless deployment across networks
Trusted Huawei Quality — Proven reliability and long-term support
Get in Touch Now
Upgrade your GPON network with the Huawei G-140W-MD ONT — a reliable, feature-rich solution for broadband access.
Request your quote today for pricing, datasheet, OEM branding, or bulk purchase details.
