H802GPBD C++ Huawei High Quality 8-Port GPON Interface Board
The H802GPBD C++ Huawei is a high-performance 8-port GPON interface board, designed for use with Huawei’s MA5600T and MA5680T OLT platforms. Equipped with Class C++ SFP optical modules, this board supports long-reach GPON deployments, making it ideal for rural broadband expansion, metro access networks, and high-split-ratio FTTH applications. Built for reliability and scalability, the H802GPBD C++ offers efficient and flexible fiber network solutions.
Key Features
-
Model: H802GPBD C++
-
Condition: 100% Brand New, Original Huawei
-
Port Count: 8 GPON Ports
-
Optical Module Type: Built-in Class C++ SFP
-
Downstream Data Rate: 2.488 Gbps
-
Upstream Data Rate: 1.244 Gbps
-
Maximum Split Ratio: 1:128 per port
-
Transmission Distance: Up to 40 km
-
Hot-Swappable: Yes – for fast replacement and scalability
-
Compatibility: MA5600T, MA5680T, MA5800 series
Technical Specifications
| Specification | Details |
|---|---|
| Model | H802GPBD |
| GPON Ports | 8 |
| SFP Type | Class C++ Optical Modules |
| Wavelengths | Tx: 1490 nm, Rx: 1310 nm |
| Max Transmission Distance | Up to 40 km |
| Tx Optical Power | +3 to +7 dBm |
| Receiver Sensitivity | -32 dBm |
| Maximum Split Ratio | 1:128 |
| Protocols Supported | ITU-T G.984.1–4, OMCI, AES encryption, DBA |
| Fiber Type | Single-mode, SC/UPC or SC/APC |
| Power Consumption | ≤ 35W (typical) |
| Operating Temperature | -25°C to +65°C |
| Relative Humidity | 5%–95% RH, non-condensing |
| Warranty | 1–3 Years Manufacturer Warranty |
H802GPBD C++ Huawei Applications
-
FTTH Deployments – Long-reach fiber access in suburban and rural areas
-
FTTB/FTTC Networks – Compact and reliable for multi-dwelling units or business parks
-
ISP Network Expansion – High split ratio and long-distance coverage for efficient scaling
-
Municipal and Government Networks – Secure and dependable broadband infrastructure
-
Enterprise Campus Solutions – Robust GPON connectivity across multiple buildings
Customization & OEM Options
-
Brand Customization – Add your company logo and custom part numbers
-
Pre-Configuration – Set ONT profiles, VLANs, service templates before shipment
-
Alternative Optics – Options for Combo PON, Class B+, or C+ modules
-
Accessory Kits – Available with pigtails, patch cords, and installation panels
-
Extended QA – Special testing for harsh or mission-critical environments
H802GPBD C++ Huawei Wholesale & Global Procurement
-
Genuine Huawei Stock – Original, sealed Huawei packaging
-
Bulk Quantities Available – Ideal for telecom project rollouts
-
Secure Export Packaging – Static-free and foam-cushioned boxing
-
Worldwide Delivery – Shipping complies with optical hardware regulations
-
Technical Support – Deployment assistance and NMS integration available
Why Choose the H802GPBD C++ Huawei
-
Long Reach Capability – Up to 40 km coverage with Class C++ optics
-
Reliable 8-Port GPON Access – Stable performance for diverse network needs
-
Carrier-Grade Huawei Quality – Widely used by ISPs and telecom providers
-
Energy Efficient & Compact – Ideal for space-constrained OLT racks
-
Future-Ready – Scalable for growing bandwidth and subscriber demands
Contact Us
Elevate your optical network with the Huawei H802GPBD C++ 8-Port GPON OLT Board — built for performance, flexibility, and long-term network growth.
