HD4103 Description:
HD4103 Optical Talk Set is an intelligent and efficient instrument that combines in one set the functions of both a digital optical phone and a stabilized light source. It is widely used in operations of installation, optical testing, maintenance and fiber attenuation value testing in data network, CATV and Telecommunication network. The HD4103 Talk Set can carry out full-duplex communication with high quality connection and not be affected by distance. FHS2Q Series Optical Laser Source is an advanced version of FHS2 Series of Optical Laser Sources, with two more calibrated wavelengths.
Features of HD4103：
1.Full-duplex digital communication
2.Together with Optical Clip-on Coupler
3.enables on line communications available
4.Large LCD display with backlight
5.Low battery power indication
6.A digital optical phone call and a stabilized light source.
7.Good conversation connection and low background noise
Auto-wavelength Recognition:
This Series Optical Laser Source transmits with a wavelength-identification digital encrypted protocol, enabling FHP2 Series Optical Power Meter to automatically use the proper calibration wavelength. This feature reduces the need for communication between the two technicians and decreases the possibility of making mistakes.
This Series Optical Laser Source offers excellent stability and portability for accurate fiber optic testing.
Two output ports provide stable laser power at four wavelengths. The compact unit operates in either continuous wave (CW) mode or modulated mode. A low battery indicator reminds the user of replacing the battery.
HD4103 Specifications:
|
Wavelength(nm)
|
1310/1550
|
|
Emitter Type
|
FP-LD
|
|
Transmission Distance(KM)
|
≥100
|
|
Dynamic Range(dB)
|
≥ 33
|
|
Output Power(dB)
|
-5~-7
|
|
Modulation(Hz)
|
CW271K2K
|
|
Output Stability(dB30min20°℃)
|
≤0.1
|
|
Power Supply
|
3 pcs 1.5V Alkaline Batteries/8.4V Power Supply Adaptor
|
|
Battery Operating Time
|
5hours
|
|
Optical Connector
|
FC/PC
|
|
Operating Temperature(°C)
|
-10~+60
|
|
Storage Temperature(°C)
|
-25~+70
|
|
Dimension(mm)
|
198X102X50
|
- Easy-to-use, straight forward operation
- Eye-catching handheld appearance
- LCD backlight for easy operation in dark environment
- Rechargeable battery inside
- Four wavelengths available for multi-purpose testing
- One-year warranty and recommended calibration interval
