SKU 1600463824567 Categories , Tag
    • Model Number: F673AV9
    • Type: ONU
    • Place of Origin: Guangdong, China
    • Brand Name: ZTE
    • Use: FTTH
    • Warranty Time:1 year
    • Network: Wired LAN, wifi
    • Supply Ability: 10000 Piece/Pieces per Month
    • Packaging Details: Retail Carton
    Product Description



    ZTE ZXHN F673AV9 FTTH is ZTE ZXHN F673AV9 FTTH is GPON optical terminal with 4GE +1POT+ 2USB and Dual-band Port.

    Model Configuration Dimension/pcs
    LAN Telephone WIFI PPPOE FIRMWARE
    F673A v2 4GE 1POTS 2.4G/5.0 SUPPORT ENGLISH 240*200*58mm/0.50kgs

    Overview

    ZTE F673AV9 is a GPON Optical Network Terminal designed for HGU (Home Gateway Unit) used in FTTH scenario, which supports L3 function to help subscribers build intelligent home networks.

    ZTE GPON ONT series products are mainly used in the construction of FTTH (fiber-to-the-home) and FTTO (fiber-to-the-office) scenarios, giving operators green environmental protection, high reliability, easy operation, and maintenance, and meeting multiple application scenarios. Even gigabit bandwidth brings endless possibilities for users’ home network service.

    Specifications

    Technical items Descriptions
    Brand ZTE
    Model F673V9
    Fiber port 4GE+1POT+1USB+WIFI, SC single-mode,
    Wavelength Tx 1310nm, Rx 1490nm
    Fiber interface SC/UPC
    RX sensitivity <-27dBm (1490nm)
    WLAN IEEE802.11b/g/n,2*2 MIMO, 2.4G/5G WIFI,external antenna(2dBi)
    2.4GHz: 2 x 2 MIMO 802.11b/g/n ,5GHz: 2 x 2 MIMO 802.11a/n/ac
    LAN 1*10/100/1000Mbps adaptive Ethernet ports, full/half duplex, RJ45 interface
    L2 forwarding capability Forwarding packets of any length at wire speed
    IPv4 L3 forwarding capability 2Gbit/s with any length packets in the downstream direction
    1Gbit/s with any length packets in the upstream direction
    IPv6 L3 forwarding capability 2Gbit/s with any length packets in the downstream direction
    1Gbit/s with any length packets in the upstream direction
    Configuration method NMS, Web, or TR069
    Voice protocol SIP, H.248
    DC power Adapter input: 100-240 V AC, 50 – 60 Hz ;
    Adapter output: 11 – 14 V DC, 1 A
    Button Reset, power
    Power ≤8W
    Operation Working temperature: -0-+40℃
    working humidity:5-95%(non-condensation)
    Dimension 250*220*65mm(length*width*height)
    Net weight ≤0.8Kg

    ZTE ZXHN F673AV9 FTTH Product Feature

    • Ultra-wide: one deployment, continuous upgrade of network capacity
      Each PON port of the POL network has a bandwidth of up to 10G. When there is a higher bandwidth requirement, the optical fiber does not need to be replaced, only the equipment or optical modules at both ends need to be replaced, simplifying the upgrade steps and saving upgrade costs.
    • Simplified: energy saving and land saving, simple operation and maintenance
      The POL solution can reduce the computer room by about 80% and can achieve energy savings of up to 60%.
      The POL network has a simple hierarchy, which is convenient for maintenance and management, reduces failure points, and improves network reliability. Network operation and maintenance expenses can be reduced by more than 60%.
    • Convergence: One optical fiber carries all services
      A set of POL networks can provide a 1000M Ethernet port, POTS, CATV, Wi-Fi, RS232/485 serial port, PoE port, time synchronization interface, etc. There is no need to establish multiple sets of networks to carry multiple services.
    • Security: Provide multiple security protection mechanisms
Specification

F673AV9A
