Huawei EA5801E-GP08 GPON OLT – 8-Port Compact OLT with Carrier-Class Performance
The Huawei EA5801E-GP08 is a compact and high-performance GPON Optical Line Terminal (OLT) designed to deliver reliable fiber-based access for small to medium-sized deployments. This model belongs to Huawei’s EA5800 series, engineered for carrier-grade performance in Fiber To The Home (FTTH), Fiber To The Building (FTTB), and Fiber To The Curb (FTTC) applications.
Key Features:
-
8 x GPON Ports
Supports up to 1024 ONUs (Optical Network Units) through GPON ports (1:128 split ratio), enabling high-capacity fiber access networks. -
2 x GE/10GE Uplink Ports (Combo SFP/SFP+)
Ensures flexible uplink connectivity with support for both Gigabit Ethernet and 10 Gigabit Ethernet SFP/SFP+ modules. -
Carrier-Class Reliability
Offers robust performance with hot-swappable components, redundancy support, and industry-standard security features for continuous operation. -
Compact & Fanless Design
Space-saving 1U form factor suitable for small cabinets and remote deployment sites. Fanless architecture ensures silent and energy-efficient operation. -
Unified Platform
Based on Huawei’s unified platform for GPON/10G GPON access, allowing for easier integration and scalability within larger networks. -
Layer 2/3 Capabilities
Includes integrated Layer 2 switching and basic Layer 3 routing functions for simplified network topologies. -
Flexible Management
Supports remote management through SNMP, CLI, and web interfaces, allowing seamless integration into existing network management systems.
Specification Huawei EA5801E-GP08 |
|
| Ambient temperature | -40℃ to +65℃ |
| Ambient humidity | 5% RH to 95% RH |
| Atmospheric pressure | 70–106 kPa |
| Working Voltage Range | DC power supply: –38.4 V to –72 V AC power supply: 100–240 V |
| Maximum Input Current | DC power supply: 6 A AC power supply: 2.5 A |
| Static Power Consumption (W) | 55W |
| Max Power Consumption (W) | 140W |
| Dimensions (mm) | Excluding mounting ears: 43.6 x 442 x 220 mm Including IEC Mounting Ears: 43.6 x 482.6 x 220 mm Including ETSI mounting ears: 43.6 x 535 x 220 mm |
| Weight (kg) | 5 |
| System switching capacity | 140 Gbit/s |
| Access ONT | 256 |
| IPv4 Routing Table | 8192 |
| IPv6 Routing Table | 4096 |
| ARP Table | 16384 |
Ideal Use Cases:
-
Rural broadband expansion
-
Small to medium-sized ISPs
-
Campus and enterprise fiber networks
-
FTTH/FTTB rollouts in suburban and urban areas
The EA5801E-GP08 is a future-ready OLT designed to bridge the digital divide and extend high-speed fiber services even to the edge of networks. It provides telecom operators, ISPs, and enterprise networks with an agile, reliable, and scalable GPON solution in a compact form.
