- Model Number:Huawei HS8145C
- Type:ONT/ONU
- Place of Origin:Zhejiang, China
- Brand Name:huawei
- Use:Home.school,hotel….
- Warranty Time:1 year
- Network:Wireless Lan, Ip, POE, wifi, 4g, Wireless Lan, Wired LAN, wifi, Wireless Lan, wifi, 4g, 5G
- model Number:HS8145c
- use:FTTX, FTTH FTTB FTTX Network
- Type::1GE+3FE/FE +1 POTS+ 1 USB+WIFI, GPON ONU
- Color:white
- Certification:CE ROHS FCC, Other
- Function::Fiber Signal Transmission
- BRAND NAME:HUAWEI
- WARRANTY time:1 Year
- Size::176mm 138.5mm 28mm
-
- Supply Ability
- 100 Carat/Carats per Day
-
- Packaging Details
1pcs 1 carton
-
- Port
shanghai ningbo shenzhen
- Picture Example:
- Lead time:Quantity(carats)1 – 1>1Lead time (days)5To be negotiated
Product Description
The EchoLife HS8145C, an optical network terminal (ONT), is a high-end home gateway in Huawei FTTH solution. By using the GPON technology, ultra-broadband access is provided for home and SOHO users.
The HS8145C provides 1* POTS ports, 1GE+3FE(or 4* FE )auto-adapting Ethernet ports, and 2* Wi-Fi port. The HS8145C features high-performance forwarding capabilities to ensure excellent experience with VoIP, Internet and HD video services. Therefore, the HS8145C provides a perfect terminal solution and future oriented service supporting capabilities for FTTH deployment.
The HS8145C provides 1* POTS ports, 1GE+3FE(or 4* FE )auto-adapting Ethernet ports, and 2* Wi-Fi port. The HS8145C features high-performance forwarding capabilities to ensure excellent experience with VoIP, Internet and HD video services. Therefore, the HS8145C provides a perfect terminal solution and future oriented service supporting capabilities for FTTH deployment.
Maintenance features
Web local management
Remote management through OMCI
Remote management through TR069
Optical power monitoring
Loop-line test of POTS ports
Call emulation
PPPoE dialup emulation
DHCP emulation
Web local management
Remote management through OMCI
Remote management through TR069
Optical power monitoring
Loop-line test of POTS ports
Call emulation
PPPoE dialup emulation
DHCP emulation
Specification
|
Technical items
|
Descriptions
|
|||
|
Fiber port
|
1 GPON interface, 1GE+3FE+2POT+1USB+WIFI,SC single-mode,
Downstream rate 2.5Gbps, Upstream rate 1.25Gbps |
|||
|
Wavelength
|
Tx 1310nm, Rx 1490nm
|
|||
|
Fiber interface
|
SC/UPC
|
|||
|
RX sensitivity
|
<-27dBm (1490nm)
|
|||
|
WLAN
|
IEEE802.11b/g/n,2*2 MIMO, 2.4G,2*External antenna
|
|||
|
LAN
|
1*10/100/1000Mbps adaptive Ethernet ports, full/half duplex, RJ45 interface
|
