- Model Number:XELD
- Type:olt card, Olt card
- Place of Origin:China
- Brand Name:huawei
- Use:Fttx
- Warranty Time:1 year
- Product name:XELD
- Ports:8 Ports
- Warranty:1 Year / 12 Months
- Brand:Huawei Original
- Keywords:XELD
- Color:Grey
- MOQ:1 PCS
- Service:After-sales Service
- Pon:1 PON SC Port
-
- Supply Ability
- 10000 Piece/Pieces per Month
-
- Packaging Details
Retail package for Huawei ONU
-
- Port
Shenzhen/Guangzhou
- Lead time:Quantity(pieces)1 – 2000>2000Lead time (days)15To be negotiated
Product Description
|
Brand
|
Huawei
|
|
Specification
|
XELD
|
|
Port quantity
|
8
|
|
MAX Split ratio
|
1: 128
|
|
Forwarding Rate
|
80Gbit/s
|
|
Rate model
|
Symmetric Rate model
|
|
Asymmetric Rate Model
|
|
|
Maximum Number of LLID
|
256
|
|
Maximum Number of Service Flows Supported by the Board
|
16368
|
|
Maximum frame length
|
2052 bytes
|
|
Maximum Number of MAC
|
16384
|
|
Maximum differential fibre distance (km)
|
60
|
|
Working temperature
|
-40℃~+65℃
|
|
Maximum Power waste
|
65w
|
|
Dimensions (W x D x H)
|
490 mm x 325mm
|
|
High-temperature automatic concern
|
Yes
|
|
Rogue ONT Detection and Isolation Support
|
Yes
|
|
Board supporting downstream FEC
|
Yes
|
|
Board supporting upstream FEC
|
Yes
|
Huawei SmartAX MA5800 series OLT products include MA5800-X17, MA5800-X15, MA5800-X7, and MA5800-X2 models.
The MA5800 multi-service access device is the industry’s first distributed architecture intelligent aggregation OLT platform, positioned as the next-generation OLT for NG-PON. The MA5800 is dedicated to helping customers build a “broader, faster, smarter” access network that provides a better business experience for their users.
The MA5800 provides GPON, XG-PON, XGS-PON, 10G-EPON, and P2P 10GE/GE access, and supports multiple network construction modes including FTTH, FTTD, FTTB, and FTTC to meet home access and enterprise access. The requirements of various service scenarios, such as mobile bearer and Wi-Fi hotspot backhaul, realize a full service of the optical fiber network.
The MA5800 combines the functions of an OLT and an aggregation switch to support unified aggregation of ONTs, MDUs, and campus switches as a large-capacity aggregation device, helping to simplify the network architecture and reduce OPEX.
The MA5800 multi-service access device is the industry’s first distributed architecture intelligent aggregation OLT platform, positioned as the next-generation OLT for NG-PON. The MA5800 is dedicated to helping customers build a “broader, faster, smarter” access network that provides a better business experience for their users.
The MA5800 provides GPON, XG-PON, XGS-PON, 10G-EPON, and P2P 10GE/GE access, and supports multiple network construction modes including FTTH, FTTD, FTTB, and FTTC to meet home access and enterprise access. The requirements of various service scenarios, such as mobile bearer and Wi-Fi hotspot backhaul, realize a full service of the optical fiber network.
The MA5800 combines the functions of an OLT and an aggregation switch to support unified aggregation of ONTs, MDUs, and campus switches as a large-capacity aggregation device, helping to simplify the network architecture and reduce OPEX.
