Huawei S5720-56PC-EI-AC Layer 3 Managed Switch – 48-Port 1000BASE-T with 4 x 10GE SFP+ Uplinks | Brand New AC-Powered Enterprise Switch
Product Overview
The Huawei S5720-56PC-EI-AC New Switch is a full-Gigabit Layer 3 managed Ethernet switch designed for enterprise campus networks, branch offices, and aggregation environments requiring both high density and flexible uplink capacity. This switch includes 48 × 10/100/1000Base-T Ethernet ports and 4 × 10GE SFP+ uplink ports, offering seamless integration into high-performance network backbones.
With a fixed AC power supply, advanced software capabilities based on Huawei’s VRP (Versatile Routing Platform), and rich Layer 2/Layer 3 feature support, the S5720-56PC-EI-AC provides enterprise-grade reliability, security, and scalability.
Huawei S5720-56PC-EI-AC New Switch Key Features
-
48 × 1000BASE-T Ethernet ports for high-density copper access
-
4 × 10GE SFP+ uplink ports for high-speed aggregation
-
Supports Layer 3 routing: static routes, RIP, OSPF, BGP
-
Intelligent traffic management with QoS, multicast, and VLAN support
-
Enhanced security: 802.1X, SSH, RADIUS, ARP inspection, port isolation
-
Built-in AC power supply (100–240V) with low power consumption
-
Suitable for rackmount installations in enterprise, government, or education networks
Huawei S5720-56PC-EI-AC New Switch Technical Specifications
| Specification | Details |
|---|---|
| Model | Huawei S5720-56PC-EI-AC |
| Forwarding Rate | 132 Mpps |
| Switching Capacity | 336 Gbps |
| Downlink Ports | 48 × 10/100/1000Base-T Ethernet |
| Uplink Ports | 4 × 10GE SFP+ |
| MAC Address Table | 32K entries |
| VLAN Support | Up to 4,000 VLANs |
| Routing Protocols | Static, RIP, OSPF, BGP, IS-IS |
| Power Supply | Fixed AC (100V–240V, 50/60Hz) |
| Operating Temperature | 0°C to 50°C |
| Dimensions (W × D × H) | 442 mm × 420 mm × 43.6 mm |
| Weight | ≤ 7.5 kg |
| Management | CLI, SNMP v1/v2/v3, Telnet, Web, Huawei eSight |
| Certifications | CE, RoHS, FCC, ISO9001, IEC |
Huawei S5720-56PC-EI-AC New Switch Application Scenarios
-
Enterprise campus access switching with copper-based client devices
-
Aggregation switch in multi-floor or departmental LANs
-
Unified voice, video, and data service delivery
-
Secure network environments requiring ARP security, IP source guard, and AAA
-
Government, education, healthcare, and SMB IT infrastructure
Technical Specifications
| Item | Description |
|---|---|
| Fixed Ports | 48×10/100/1000Base-T Ethernet ports, 4×Gigabit SFP ports |
| Forwarding Performance | 108 Mpps |
| Extended Slot | One slot for uplink interface card or private stack card |
| DRAM & Flash | SDRAM: 2 GB, Flash: 340 MB |
| MAC Address Table | IEEE 802.1d, 64K MAC entries, learning & aging, static/dynamic/blackhole MACs, source MAC-based filtering |
| VLAN | 4K VLANs, Guest & Voice VLAN, GVRP, MUX VLAN, MAC/protocol/IP/policy/port-based assignment, 1:1 & N:1 mapping, transparent protocol transmission |
| Jumbo Frame | 12K |
| Ring Protection | RRPP, Smart Link, SEP, G.8032 ERPS, STP, RSTP, MSTP, BPDU protection, loop/root protection, BPDU tunnel |
| IP Routing | Static, RIPv1/2, RIPng, OSPF/v3, IS-IS/v6, BGP/BGP4+, ECMP, PBR, 16K IPv4 & 8K IPv6 routes, 3K IPv4 static, 1K IPv6 static |
| IPv6 Features | ND, PMTU, Ping/Tracert/Telnet, 6to4, ISATAP, tunnels, ACLs, MLD v1/v2 snooping |
| Multicast Forwarding | IGMP v1/v2/v3 snooping, fast leave, VLAN replication, load balancing, controllable, Layer 2 control, port stats, PIM-SM/DM/SSM, MSDP |
| QoS/ACL | Traffic rate limiting, redirection, storm control, CAR, 8 queues/port, WRR, DRR, SP, queue shaping, WRED, L2–L4 filtering, DSCP & 802.1p remarking, port/VLAN mirroring |
| Security Features | User/password management, DoS/ARP/ICMP protection, IP-MAC-VLAN binding, port isolation, sticky MAC, MFF, MAC blackholing, 802.1x, AAA, RADIUS, HWTACACS+, NAC, HTTPS, SSH v2.0, MACSec ready, CPU defense, blacklist/whitelist |
| Access Security | DHCP Relay, Server, Snooping, Client, Security |
| Port Aggregation | LACP, 128 trunks, 8 members per group |
| Reliability | Ethernet OAM (802.3ah, 802.1ag), ITU-Y.1731, BFD for BGP/IS-IS/OSPF/static |
| SVF (Super Virtual Fabric) | SVF client with plug-and-play, auto software & config delivery, supports independent client operation |
| Management & Maintenance | iStack, VCT, SNMP v1/v2c/v3, RMON, Web NMS, logs & alarms, sFlow, LLDP/LLDP-MED, 802.3az EEE, SCP, TFTP, FTP, dual images/configs |
| Interoperability | VLAN Spanning Tree (PVST/PVST+/RPVST), LNP (like DTP), VCMP (like VTP) |
| Operating Environment | 0–1800 m: 0–45℃; 1800–5000 m: –1℃ per +220 m; Relative Humidity: 5%–95% (non-condensing) |
| Input Voltage | AC: 100–240 V (rated), 90–264 V (max), 50/60 Hz |
| Dimensions (mm) | 442 (W) × 220 (D) × 43.6 (H) |
| Typical Power Consumption | 39.3 W |
Wholesale & Customization Services
-
Bulk availability for system integrators, resellers, and national rollouts
-
Includes manufacturer’s test report, RoHS/CE certifications, and warranty
-
Optional OEM/private label branding and pre-configuration services
-
Fast delivery and support for project-based deployments and IT tenders
-
Matching Huawei accessories, transceivers, and management software available
Why Choose the Huawei S5720-56PC-EI-AC Switch?
-
High-performance 48-port Gigabit access with advanced Layer 3 features
-
Cost-effective and energy-efficient for long-term enterprise deployment
-
Carrier-class stability with Huawei’s trusted switching architecture
-
Easy integration with existing networks via standardized protocols
-
Suitable for growing bandwidth and security demands in modern infrastructures
Request a Quote
Power your enterprise network with the Huawei S5720-56PC-EI-AC Switch—a smart, scalable solution for high-density Gigabit switching and 10G uplink aggregation.
