Huawei SecPath F1000-AI-80 Next-Generation AI Firewall
The Huawei SecPath F1000-AI-80 is a state-of-the-art next-generation firewall that leverages artificial intelligence and big data analytics to deliver high-performance security for large enterprises, service providers, and data centers. The F1000-AI-80 is equipped with advanced security features, such as AI-based threat detection, deep traffic inspection, SSL decryption, and automated threat mitigation, making it ideal for environments with high traffic volumes and complex security needs.
Its robust throughput, comprehensive security services, and AI-driven intelligence enable businesses to predict and prevent cyberattacks while ensuring network performance and data privacy.
SecPath F1000-AI-60 Key Features
-
🔹 AI-Based Threat Detection and Analysis: Uses AI engines for intelligent security threat prediction and defense.
-
🔹 High Throughput Performance: Up to 90 Gbps firewall throughput (F1000-AI-90).
-
🔹 Integrated Threat Prevention: Built-in IPS, antivirus, URL filtering, DDoS protection, and advanced threat defense.
-
🔹 Cloud-Network Security Convergence: Seamless security for hybrid cloud environments.
-
🔹 VPN Support: Secure remote access via IPSec VPN, SSL VPN, and L2TP VPN.
-
🔹 Flexible High-Speed Interfaces: Supports GE, 10GE, 40GE ports (model-dependent).
-
🔹 Smart Policy Management: Dynamically adjusts security policies based on user behavior and threat conditions.
-
🔹 Energy Efficient and Compact: High-density design with optimized power usage.
-
🔹 High Availability (HA): Dual system redundancy and failover supported.
Product Specifications:
| Feature | F1000-AI-90 | F1000-AI-80 | F1000-AI-70 | F1000-AI-60 |
|---|---|---|---|---|
| Firewall Throughput | 90 Gbps | 80 Gbps | 70 Gbps | 60 Gbps |
| IPS Throughput | 45 Gbps | 40 Gbps | 35 Gbps | 30 Gbps |
| Concurrent Sessions | 40 million | 35 million | 30 million | 25 million |
| New Sessions per Second | 800,000 | 700,000 | 600,000 | 500,000 |
| VPN Throughput | 18 Gbps | 16 Gbps | 14 Gbps | 12 Gbps |
| Interfaces | GE/10GE/40GE | GE/10GE/40GE | GE/10GE | GE/10GE |
| AI Threat Detection | Supported | Supported | Supported | Supported |
| Management | Web UI, CLI, SNMP, Cloud Mgmt | Web UI, CLI, SNMP, Cloud Mgmt | Web UI, CLI, SNMP, Cloud Mgmt | Web UI, CLI, SNMP, Cloud Mgmt |
| High Availability (HA) | Active-Standby/Load Balancing | Active-Standby/Load Balancing | Active-Standby/Load Balancing | Active-Standby/Load Balancing |
| Power Supply | Dual AC/DC redundant | Dual AC/DC redundant | Dual AC/DC redundant | Dual AC/DC redundant |
| Dimensions (W×D×H) | ~442 × 600 × 88 mm | ~442 × 600 × 88 mm | ~442 × 600 × 88 mm | ~442 × 600 × 88 mm |
| Weight | ~17 kg | ~17 kg | ~16 kg | ~16 kg |
| Operating Temperature | 0°C to 45°C | 0°C to 45°C | 0°C to 45°C | 0°C to 45°C |
Specifications
SecPath F1000-AI-80 |
|
| Ports | 1 × Console port (CON) |
| 2 × Management port | |
| 8 × Gigabit Ethernet fiber ports | |
| 14 × Gigabit Ethernet copper ports | |
| 8 × 10-Gigabit Ethernet fiber ports | |
| Expansion slots | 4 |
| Interface modules | 4-port GE PFC interface module |
| 4-port GE fiber interface module | |
| Storage | 480G/960G/1.92T SSD |
| 1T HDD | |
| Flash | 8GB |
| SDRAM | 16G |
| Physical specifications | |
| Dimensions (W × D × H) | 440mm×435mm×44mm |
| USB | 2 |
| rack mounted | Yes |
| Weight | 10kg |
| Power Supply | Dual hot-swappable, AC or DC |
| Power consumption | 180W |
| Temperature | Operating: 0°C to 45°C (32°F to 113°F) |
| Storage: –40°C to +70°C (–40°F to +158°F) | |
| Operation modes | Route, transparent, and hybrid |
Application Scenarios
-
Large Enterprise Core Firewall
-
Protect core networks with AI-enhanced, high-performance threat defense.
-
-
Secure Multi-Branch Connectivity
-
Safeguard communication between headquarters, branches, and cloud environments.
-
-
Cloud Edge Security Gateway
-
Extend AI-driven security across hybrid and multi-cloud deployments.
-
-
Data Center Edge Protection
-
Provide intelligent, scalable protection at the perimeter of data centers.
-
-
AI-Driven Security Operations
-
Enable security operations centers (SOCs) to leverage intelligent threat prediction and policy optimization.
-
