LC/UPC 15dB Description
The LC/UPC 15dB Fiber Optical Attenuator is a brand new, high-precision male-to-female inline optical attenuator, specifically designed to reduce the optical signal strength by 15 decibels (dB) in single-mode fiber optic networks. This fixed-value attenuator is essential for maintaining optimal power levels, protecting sensitive receivers from overloading, and ensuring high-performance network operation.
Manufactured to international telecom standards, this LC/UPC attenuator features low insertion loss, high return loss, and excellent repeatability. Its compact, plug-and-play design makes it ideal for use in telecommunication systems, CATV networks, data centers, test environments, and FTTH applications.
Key Features
-
Type: LC/UPC Male-Female Fiber Optical Attenuator
-
Attenuation Level: 15dB fixed
-
Connector: LC/UPC standard polish with precision ceramic ferrule
-
Performance: Consistent, accurate attenuation with low insertion loss and high return loss
-
Compatibility: Suitable for single-mode fiber optic systems and standard LC/UPC interfaces
-
Condition: 100% Brand New, factory-tested for accuracy
-
Application: Inline signal adjustment to balance optical power levels and protect network devices
Tech Specs
Product Information
| Attribute | Specification |
|---|---|
| Product Name | LC/UPC 15dB Male-Female Fixed Fiber Optical Attenuator |
| Fiber Connector | LC/UPC |
| Connector Gender | Male-Female |
| Transfer Mode | Singlemode |
| Material | Ceramic |
Optical Performance
| Attribute | Specification |
|---|---|
| Operating Wavelength (nm) | 1200 nm – 1600 nm |
| Attenuation | 15 dB |
| Attenuation Accuracy | ±10% dB |
| Return Loss | > 20 dB |
| Interchangeability | ≤ 0.20 dB |
| Repeatability | ≤ 0.10 dB |
| Reliability | > 1000 plugs |
Environmental Parameters
| Attribute | Specification |
|---|---|
| Operating Temperature Range | –40°C ~ +80°C |
| Storage Temperature Range | –40°C ~ +85°C |
| Vibration | Amplitude: 1.52 mm Frequency: 10 Hz – 55 Hz |
LC/UPC 15dB Applications
This LC/UPC 15dB attenuator is ideal for:
• Reducing excessive optical signal levels in transmission lines
• Preventing receiver saturation in telecom and CATV networks
• Data center interconnects and backbone network links
• FTTH (Fiber To The Home) systems and ODN applications
• Test and measurement labs requiring precise optical signal control
Customization & OEM Services
We offer flexible customization and OEM solutions for our fiber optical attenuators to meet your specific project needs:
• Available attenuation levels from 1dB up to 30dB
• Various connector types: LC, SC, FC, ST with UPC/APC polish options
• Private labeling and custom logo branding for resellers and distributors
• Custom packaging for bulk shipments and project rollouts
• Special burn-in testing available for high-availability applications
LC/UPC 15dB Wholesale & Bulk Orders
Partner with us for reliable wholesale supply and large-volume purchasing:
• Factory-direct pricing with attractive volume discounts
• Stable stock availability and flexible lead times
• Global shipping with secure, export-compliant packaging
• Fast order processing and dedicated account management for big projects
• Full technical support and after-sales service for peace of mind
LC/UPC 15dB Why Choose Us
✅ High-Precision Fiber Components — tested for consistent, accurate attenuation
✅ Wide Range of Options — multiple connector types and attenuation values available
✅ Competitive Wholesale Pricing — ideal for carriers, ISPs, and network contractors
✅ Professional Packaging & Global Logistics — safe delivery, anywhere in the world
✅ Expert Assistance — from selection to after-sales support
Contact Us for a Quote
Achieve stable, balanced optical signals with the LC/UPC 15dB Brand New Male-Female Fiber Optical Attenuator — your trusted solution for precise network power management. Contact our team today for technical specifications, bulk pricing, or customization options. We’re ready to help you optimize your fiber network with high-quality, reliable optical components.
