- Model Number:echolife HG8321V
- Type:ONU ONT
- Place of Origin:Guangdong, China
- Brand Name:echolife HG8321V
- Use:FTTH Solutions
- Warranty Time:1 Year
- Network:Wireless Lan
- Model:echolife HG8321V
- Dimensions:167(L)*118(W)*30(H)
- Weight:200g
- Operating Temperature:0°C to +40°C
- Operating Humidity:5% RH to 95% RH (non-condensing)
- Power Adapter Input:100 V to 240 V AC, 50 Hz/60 Hz
- System Power Supply:11 V to 14 V DC, 1.5 A
- Configuration:1GE+1FE+1POTS+ 1 CATV/RF Port
- Selling Units:Single item
- Single package size: 15X13X7 cm
- Single gross weight:1.000 kg
- Package Type:CARTON BOX PACKING
- Picture Example:
- Lead time:Quantity(pieces)1 – 2000>2000Lead time (days)15To be negotiated
Low Price Original brand new HG8321V XPON 1GE 1FE 1tel CATV echolife HG8321V
HG8321V FTTH is a bridging-type ONT used in the all-optical access solution. The product implements ultra-broadband access through the GPON technology. At the same time, HG8321V provides 1 GE port 1FE Portand 1 RF port. The high-performance forwarding capability ensures the service experience of CATV,data and HD video services, and offers users with ideal terminal solutions and future-oriented service support capabilities.
|
Type
|
Optic Fiber
|
|
Color
|
White
|
|
Weight
|
200g
|
|
Power Adapter Input
|
150V ～ 264V AC，50Hz ～ 60Hz
|
|
Power Supply
|
External Power Adapter 12V/1A
|
|
Power Interface Size
|
metal inner diameter: φ2.1±0.1mmouter diameter : φ5.5±0.1mm; length: 9.0±0.1mm
|
|
WLAN Module
|
External dual antenna, antenna gain 5db, antenna power 16~21dbm
|
|
Support 2.4GHz, 300M transmission rate
|
|
|
Operating Environment
|
Temperature: -10°C ~ 55°C
|
|
Humidity: 5% ~ 95% (no condensation)
|
Products Description
Product Paramenters
Product Features:
* Full compatible with ITU-T G.984
* Support software online upgrading
* Support Dynamic Bandwidth Allocation (DBA)
* Support broadcasting storm resistance function
* Support port isolation between different ports
* Support port-based rate limitation and bandwidth control
* Support ACL and SNMP to configure data packet filter flexibly
* Integrated OMCI remote configuration and maintenance function.
* Support ONT auto-discovery/Link detection/remote upgrade of software;
* Support VLAN division and user separation to avoid broadcast storm;
* Specialized design for system breakdown prevention to maintain stable system
* EMS network management based on SNMP ,convenient for maintenance
Application
Typical Solution：FTTH(Fiber To The Home)
Typical Business：INTERNET、IPTV、WIFI 、VOIP etc
