MA5683T Huawei Brand New GPON OLT SmartAX Subrack Equipped
The MA5683T Huawei is a high-performance GPON Optical Line Terminal (OLT) subrack from Huawei’s SmartAX series, tailored for carrier-grade access networks. Designed for high-density fiber deployments, the MA5683T supports GPON, XG-PON, GE, 10GE, and POTS interfaces, making it ideal for FTTH (Fiber To The Home), FTTB (Fiber To The Building), and enterprise broadband services. Compact yet powerful, the MA5683T subrack supports multiple service boards and is equipped with redundant control boards, uplinks, and power modules.
Key Features
-
Model: MA5683T SmartAX OLT
-
Condition: 100% Brand New, Original Huawei
-
Subrack Type: Compact OLT chassis
-
Service Slots: 6 service slots, 2 uplink slots, 2 control board slots
-
GPON Compatibility: Supports GPON, XG-PON, XGS-PON
-
Integrated Support: Data, voice (POTS), video, and Layer 2/Layer 3 services
-
Redundancy: Dual control board and power module options
-
Hot-Swappable: All boards support hot-swap functionality
-
Chassis Size: 19-inch rack-mountable (3U height)
Technical Specifications
| Specification | Details |
|---|---|
| Model | MA5683T SmartAX OLT |
| Subrack Dimensions | 442 mm (W) x 220 mm (D) x 132.5 mm (H) |
| Weight (Empty) | ~8 kg |
| Service Slots | 6 for GPON/XG-PON/POTS/GE boards |
| Control Board Slots | 2 (for dual redundancy) |
| Uplink Slots | 2 (GE/10GE interfaces) |
| Power Slots | 2 DC/AC options (dual power support) |
| Switching Capacity | Up to 480 Gbps backplane |
| Max ONT Connections | 8K–16K (depending on split ratio and configuration) |
| Transmission Standard | ITU-T G.984, G.987, G.988 |
| Operating Temperature | -25°C to +65°C |
| Humidity | 5% to 95% RH (non-condensing) |
| Mounting | 19-inch standard rack, ETSI compatible |
| Management | CLI, SNMP, Web GUI, and Huawei U2000/NMS |
MA5683T Huawei Applications
-
FTTH Deployments – High-speed residential broadband
-
FTTB Access – Enterprise fiber aggregation and building access
-
Triple Play Services – IPTV, voice, and high-speed internet delivery
-
Metro & Rural Access – Scalable and compact solution for wide-area deployment
-
Business VPN Services – Secure L2/L3 services for enterprise networks
Customization & OEM Options
-
Custom Configuration – Preinstalled control boards, uplink cards, and GPON boards
-
Labeling & Branding – Your company name/logo on the chassis and packaging
-
Deployment Accessories – Cable management, patch panels, and SFP modules
-
Firmware Versioning – Loaded with specified software release version
MA5683T Huawei Wholesale & Global Supply Options
-
Original Huawei Stock – Direct from manufacturer with serial verification
-
Bulk Orders Available – For ISPs, telecom operators, and distributors
-
Fast Global Shipping – Certified export packaging with compliance documents
-
Technical Support – Optional remote configuration and onboarding services
Why Choose MA5683T Huawei
-
Carrier-Grade Performance – Trusted by major global operators
-
Compact 3U Form Factor – Ideal for space-constrained deployments
-
Multi-Service Support – Seamless data, voice, and video over fiber
-
High Reliability – Redundant control and power options
-
Future-Proof – Scalable for next-gen PON (XG-PON/XGS-PON) upgrades
Contact Us Today
Upgrade your access network with the Huawei MA5683T GPON OLT — a versatile, high-density platform for next-generation broadband service delivery.
