NE8000 F8 Huawei Description
The NE8000 F8 Huawei is a high-performance, carrier-grade aggregation router designed to meet the ever-growing demands of modern IP backbone networks, large-scale enterprise WANs, and cloud data center interconnections. As part of Huawei’s trusted NetEngine 8000 series, the NE8000 F8 offers exceptional scalability, ultra-high forwarding performance, and industry-leading reliability.
Engineered for 10GE/GE aggregation, the NE8000 F8 enables operators and enterprises to deliver ultra-broadband services, 5G transport, and next-generation network applications with confidence. Its advanced hardware architecture and intelligent management features ensure low latency, high throughput, and seamless scalability for future network growth.
Key Features
-
Model: NE8000 F8
-
Condition: 100% Brand New, Original Huawei
-
Type: High-Quality 10GE/GE Aggregation Router
-
Forwarding Capacity: Delivers ultra-high throughput for large-scale service aggregation
-
Flexibility: Supports multiple interface types and service scenarios
-
Reliability: Carrier-grade hardware design for 99.999% availability
-
Energy Efficiency: Advanced power-saving technologies reduce OPEX
-
Intelligent O&M: Supports network automation and simplified management
-
Compatibility: Seamlessly integrates into Huawei’s IP backbone and metro networks
Tech Specs
| Specifications | Details |
|---|---|
| Cabinet installation standards | Can be installed in a standard 19-inch cabinet, single door, ≥ 600 mm deep. Default cabinet: Huawei A66E (600 mm x 2200 mm), PN: 02116432 (ES1BA66E0000). Optional cabinet: Huawei N68E (800 mm x 2200 mm), PN: 02115156 (CR5BRACK2201). Note: If using a third-party cabinet, front door must have air filter; rear door must be filter-free. |
| Dimensions with packaging (mm) | 835 (H) x 765 (W) x 725 (D) |
| Chassis height [U] | 13U |
| Weight with packaging [kg] | 87 kg |
| Weight with packaging (full config) | 2T bundle: 152.8 kg 6.4T bundle: 154.2 kg |
| Typical power consumption (with config) | 2T: 1684.1 W (8 LPUTs, 20 x 10x10GE ports, 8 x 10xGE ports) 6.4T: 2370 W (4 x 8x100GE ports, 4 x 72x10GE ports) |
| Typical heat dissipation (with config) | 2T: 5262.6 BTU/hour 6.4T: 7558.1 BTU/hour |
| MTBF | 38.41 years |
| MTTR | 0.5 hour |
| Availability | 0.999998514 |
| Power supply mode | DC built-in, AC/HVDC built-in |
| Max power chassis inputs | DC: (2 ch/PM) x 6 PMs = 12 channels AC/HVDC: (1 ch/PM) x 6 PMs = 6 channels |
| Rated input voltage | DC: –48 V / –60 V AC: 100–130 V (dual-live wire) / 200–240 V HVDC: 240 V |
| Input voltage range | DC: –40 V to –72 V AC: 90 V to 290 V HVDC: 190 V to 290 V |
| Heat dissipation mode | Air cooling |
| Airflow direction | Front-to-back airflow + left-to-rear airflow |
| Noise at normal temp (acoustic power) | < 78 dB(A) @ 27°C |
| Number of slots | 12 |
| Number of service board slots | 8 |
| Switching capacity | 2T bundle: 11.35 Tbit/s (Formula: 2 SRUs × 28.125 SerDes rate × 64/66 × 2) 6.4T bundle: 28.86 Tbit/s (Formula: 2 SRUs × 58.125 SerDes rate × 64/66 × 2) |
| Redundant MPUs | 1+1 |
| Redundant Switch fabrics | 1+1 |
| Redundant power supply | DC: [2T] 2+1, [6.4T] 2+1 AC: [2T] 1+1, [6.4T] 2+2 |
| Redundant fans | Two fans configured by default; system can run briefly with one fan failed |
| Storage temperature | –40°C to +70°C (–40°F to +158°F) |
| Operating temperature | Long-term: 0°C to +45°C (32°F to 113°F) Short-term: –5°C to +55°C (23°F to 131°F) |
| Storage relative humidity | 5% RH to 95% RH, non-condensing |
| Operating relative humidity | Long-term: 5% RH to 85% RH, non-condensing Short-term: 5% RH to 95% RH, non-condensing |
| Storage altitude | < 5000 m |
NE8000 F8 Huawei Applications
The NE8000 F8 Aggregation Router is ideal for:
• ISP and carrier backbone and metro network aggregation
• 5G transport network deployment
• Large enterprise WAN and data center interconnects (DCI)
• Cloud service provider edge networks
• Upgrading legacy aggregation routers to support ultra-broadband and high-density services
Customization & OEM Services
We offer flexible customization and OEM solutions to match your unique project requirements:
• Pre-configuration for rapid on-site deployment
• Custom interface module selection based on your network plan
• Private labeling and branding for distributors and system integrators
• Custom packaging for bulk shipments and multi-site rollouts
• Extended burn-in testing for mission-critical environments
NE8000 F8 Huawei Wholesale & Bulk Orders
Partner with us for wholesale supply and bulk procurement of Huawei NE8000 F8 routers:
• Factory-direct pricing with competitive volume discounts
• Global shipping with professional export packaging
• Dedicated account managers for large-scale projects
• Consistent stock availability to support urgent deployments
• Full technical support and warranty services for peace of mind
Why Choose Us
✔️ 100% Original Huawei Hardware — thoroughly tested and certified
✔️ Flexible Solutions — tailored to meet complex network requirements
✔️ Competitive Wholesale Pricing — ideal for telecom operators and system integrators
✔️ Secure Global Logistics — fast, safe delivery to any location
✔️ Reliable Technical Support — expert assistance throughout your project lifecycle
Contact Us for a Quote
Empower your network with the NE8000 F8 Huawei High Quality 10GE/GE Aggregation Router and stay ahead of tomorrow’s connectivity needs. Contact us today for technical specifications, custom configurations, or bulk pricing. Our team is ready to help you deploy a scalable, next-generation network with trusted Huawei solutions.
