- Model Number:MA 5683t
- Type:OLT, OLT
- Place of Origin:China
- Brand Name:huawei
- Use:FTTX
- Warranty Time:1 YEAR, 1 year
- Product name:MA5680t
- Package:Carton Box
- Ports:16 Ports
- Dimensions:490 x 275 x 447
- Feature:safety
- MOQ:1
- Keywords:high quality
- Brand:huawei
-
- Supply Ability
- 1000 Piece/Pieces per Week
-
- Packaging Details
carton Package
-
- Port
Shenzhen
- Lead time:Quantity(pieces)1 – 2000>2000Lead time (days)15To be negotiated
Product Description
|
Model No.
|
MA5680T
|
MA5683T
|
MA5608T
|
|
Dimension:
|
490*275.8*447.2mm
|
442*283.2*263mm
|
442*233.5*88mm
|
|
Operating Environment
|
Temperature: -25℃~+55℃
Humidity:5%~95% (non-condensing) |
Temperature: -40℃~+65℃
Humidity:5%~95% (non-condensing) |
Temperature: -40℃~+65℃
Humidity:5%~95% (non-condensing) |
|
Power SupplyParameters
|
-48V DCinputSupports dual power
protection Working Voltage range-38.4V~-72V |
-48V DCinputSupports dual power
protection Working Voltage range-38.4V~-72V |
-48V DCinputSupports dual power
protection Working Voltage range-38.4V~-72V |
|
Backplane Exchange capacity
|
3.2Tbit/s
|
1.5Tbit/s
|
720Gbit/s
|
|
Control Board Exchange Capacity
|
1920 Gbit/s
|
960Gbit/s
|
512Gbit/s
|
|
Access Capacity
|
128*10GEPON64*10G GPON
128*EPON 256*GPON 768*GE |
48*10GEPON24*10G GPON
48*EPON 96*GPON 288*GE |
16*10GEPON8*10G GPON
16*EPON 32*GPON 96*GE |
|
Upstream interface:10GE opticalGE optical/electricity Access Type Business interface: EPON optical portGPON optical port10G EPON
optical port,P2P FE optical port,P2P GE optical portEthernet optical interface |
|||
|
Layer 2/ Layer 3 wire-speed forwarding Support static router/RIP/OSPE.MPLS System
BITS/E1/STM-1/Ethernet/1588v2/1PPS+ToD clock Maximum support 1:256 splitting ratio Maximum support 60KM logical distance |
MA5680T can be used as OLT equipmentterminal ONT eguipment or other ONU equipment in the PON system: it can meet various FTTx networking applicationssuch as:FTTH(Fiber To The HomeFTB(Fiber To The Building.FTIC( Fiber To The Curbetomeet the networkina reauirements of base station transmission.IP private line interconnection wholesale and other services;support P2P FE optical access services,and provide users with point-to-pointFTTH access by cooperating with optical access terminals. The SmartAX MA5680T series products include the large-capacity SmartAX MA5680Tthe medium-capacity SmartAX MA5683Tand the MINI-type SmartAX MA5608T.The hardware and software are fully compatible, saving network stocking costs.Among the two specificationsthe large-capacity SmartAX MA5680T can provide 16 service slots, the medium-capacity SmartAX MA5683T can provide 6 service slotsand theMINl-type SmartAX MA5608 provides 2 service slots.
AggregateAccess:
—–Ultra-high convergence switching capacity,3.2T backplane capacity1920G switching capacity,512G MAC address
capacity;
capacity;
—–Ultra-high-density cascade capabilitymaximum support for 44-channel 10GE or 768 GE access, no additional investment aggregation switch.
High Reliability:
—–Highly reliable networking capabilities,support OLT dual hot backupoff-site capacity, upgrade business is
not interrupted
not interrupted
—–Complete QoS function,support traffic classification managementpriority control, with paragraph control.H-QoS
functions to meet SLA requirements for diverse business customers.
functions to meet SLA requirements for diverse business customers.
—–End-to end high reliability design,uplink support
BFD/Smart Link/LACP redundancy protection,support EPON TypeB/TypeD and GPON TypeB/TypeC line protection.
BFD/Smart Link/LACP redundancy protection,support EPON TypeB/TypeD and GPON TypeB/TypeC line protection.
Multi-scene access:
—–Avariety of E1 line access,support Native TDM or CESoP/SAToP function
—–Avariety of E1 line access,support Native TDM or CESoP/SAToP function
—–Support E-LAN function to achieve internal traffic
flow based on VLAN to meet the enterprise and campus network applications
flow based on VLAN to meet the enterprise and campus network applications
—–Support IPTV users without convergence
access,single-frame support 8000 multicast users and 4000 multicast channels.
access,single-frame support 8000 multicast users and 4000 multicast channels.
