Product Description
Roteador huawei fibra otica hg8245q2 gpon onu HG8245Q2 GPON ONU 4GE+1TEL+2USB+WIFI (2.4G&5G)Dual Band
The EchoLife HG8245Q2 is a routing-type ONT in the all-optical access solution. It uses the GPON technology to implement
ultra-broadband access for users.
ultra-broadband access for users.
It provides 4 GE+2 POTS+1 USB+2 WiFi(4 GE ports, 2 POTS ports, 1 USB port, 1 2.4G WiFi port and 1 5G WiFi port). The high
forwarding performance ensures the user experience of voice, data and HD video services, and provides customers with an ideal
all-optical access solution and future-oriented service support capability.
Application and Advantage:
1.Full compatible with ITU-T G.984.
2.Support port-based rate limitation and bandwidth control
3.Integrated OMCI remote configuration and maintenance function.
4.Support data enscryption, group broadcasting, port Vlan separation ,RSTP,etc.
5.Support Dynamic Bandwidth Allocation (DBA)
6.Support ONT auto-discovery/Link detection/remote upgrade of software;
7.Support VLAN division and user separation to avoid broadcast storm;
8.Support power-off alarm function ,easy for link problem detection
9.Support broadcasting storm resistance function
10.Support port isolation between different ports
11.Support ACL and SNMP to configure data packet filter flexibly
12.Specialized design for system breakdown prevention to maintain stable system
13.Support software online upgrading
14.EMS network management based on SNMP ,convenient for maintenance
2.Support port-based rate limitation and bandwidth control
3.Integrated OMCI remote configuration and maintenance function.
4.Support data enscryption, group broadcasting, port Vlan separation ,RSTP,etc.
5.Support Dynamic Bandwidth Allocation (DBA)
6.Support ONT auto-discovery/Link detection/remote upgrade of software;
7.Support VLAN division and user separation to avoid broadcast storm;
8.Support power-off alarm function ,easy for link problem detection
9.Support broadcasting storm resistance function
10.Support port isolation between different ports
11.Support ACL and SNMP to configure data packet filter flexibly
12.Specialized design for system breakdown prevention to maintain stable system
13.Support software online upgrading
14.EMS network management based on SNMP ,convenient for maintenance
Specification
|
Product
|
Function
|
|
HG8245Q2
|
4 Ethernet ports
|
|
2 POTS ports
|
|
|
1 USB port
|
|
|
2.4G (3*3 MIMO)+ 5G (3*3 MIMO)
|
|
Item
|
Specification
|
|
Dimensions (L x W x H)
|
265 mm x 82 mm x 176 mm
|
|
Weight (including the power adapter)
|
about 1.5 kg
|
|
System power supply
|
11 V – 14 V DC, 2 A
|
|
Power adapter input
|
100 V – 240 V AC, 50 Hz – 60 Hz
|
|
Maximum power consumption
|
20.5 W
|
|
Operating temperature
|
0ºC – +40ºC
|
|
Operating humidity
|
5% – 95% RH (non-condensing)
|
