S1720-28GWR-PWR-4TP Huawei Original New 24-Ports Power Fixed Switch
The S1720-28GWR-PWR-4TP Huawei is a high-performance, Layer 2 gigabit PoE switch, designed to meet the networking demands of enterprise access layers, campus networks, and surveillance systems. Featuring 24 Gigabit Ethernet ports with PoE/PoE+ support and 4 uplink combo ports (GE SFP/RJ45), this switch provides robust data forwarding, power delivery, and secure network management in a compact form factor.
This model combines Huawei’s energy-efficient architecture, enterprise-grade security, and silent operation for optimal deployment in noise-sensitive environments such as offices, hotels, and schools.
Key Features
- Model: S1720-28GWR-PWR-4TP
- Condition: 100% Brand New & Original Huawei OEM
- Ports: 24 × GE PoE (10/100/1000BASE-T), 4 × GE Combo (SFP/RJ45)
- PoE Output: Supports IEEE 802.3af/at with a total power budget up to 370W
- Switching Capacity: 56 Gbps
- Forwarding Rate: 42 Mpps
- Management: Web GUI, SNMP, CLI via console
- Layer 2 Support: VLAN, STP, IGMP Snooping, Port Isolation, QoS
- Security: Port Security, Storm Control, DHCP Snooping
- Energy Efficiency: Supports EEE (Energy Efficient Ethernet)
- Installation: 1U Rack Mountable
Technical Specifications
| Specification | Details |
|---|---|
| Model | S1720-28GWR-PWR-4TP |
| GE Ports | 24 × 10/100/1000BASE-T (PoE supported) |
| Uplink Ports | 4 × GE Combo (RJ45/SFP) |
| PoE Standards | IEEE 802.3af/802.3at |
| Max PoE Output Power | 370W |
| Switching Capacity | 56 Gbps |
| Forwarding Performance | 42 Mpps |
| MAC Address Table | 8K |
| VLANs Supported | 4K |
| Dimensions (W×D×H) | 442 × 220 × 43.6 mm |
| Weight | ≤4.5 kg |
| Power Supply | Built-in AC Power (100V–240V) |
| Operating Temperature | 0°C to +45°C |
| Storage Temperature | -40°C to +70°C |
| Relative Humidity | 5%–95% RH, non-condensing |
| Warranty | 1–3 Years Manufacturer Warranty |
S1720-28GWR-PWR-4TP Huawei Applications
- Enterprise Office Networks – Delivers both power and data to IP phones, cameras, and access points
- Hotel & Hospitality Networks – Quiet and reliable power to devices in sensitive environments
- Education Sector – Classroom and lab networks with PoE for APs and terminals
- Retail Chains – Remote branch switches with centralized management and PoE
- Video Surveillance Systems – Direct powering of IP cameras with VLAN separation
Customization & OEM Options
- OEM Branding – Company logo and product labeling available
- Preloaded Configurations – Customized port profiles, VLAN setup, and PoE scheduling
- Matching SFP Module Bundles – Combine with Huawei SFP transceivers for complete solution
- Power Supply Customization – Adapt for 110V/220V regional power standards
- Compliance Documentation – Country-specific CE, FCC, RoHS certifications
- Extended Environmental Options – Fanless or rugged versions available on request
Wholesale & Global Supply Information
- Huawei Original OEM Supply – Certified inventory with official serials
- Global Shipping Support – Professionally packaged, export-compliant logistics
- Volume Pricing Available – Bulk discounts for resellers and large projects
- Ready Stock – Quick dispatch and delivery
- Full Technical Support – Setup, compatibility, and deployment assistance included
- Datasheets & Manuals – Full documentation for installers and IT admins
Why Choose the S1720-28GWR-PWR-4TP Huawei
Combo Uplink Ports – Flexibility to use fiber or copper uplinks
Reliable PoE/PoE+ Power – Power IP phones, cameras, APs with ease
Silent Design – Quiet operation for office or front-desk environments
Enterprise-Class Quality – Built to Huawei’s global standards
Cost-Effective Deployment – Ideal for budget-conscious high-density installs
Contact Us for a Quote, Bulk Orders & OEM Options
Upgrade your network infrastructure with the Huawei S1720-28GWR-PWR-4TP — delivering high-speed data and PoE power in one reliable device.
Request a custom quote today for wholesale pricing, OEM branding, and fast international shipping.
