S2700-26TP-EI-AC Huawei High Quality 24-Port Ethernet Switch with Fixed AC Power
The S2700-26TP-EI-AC Huawei is a high-performance Layer 2 Ethernet switch, part of Huawei’s S2700 Enterprise series. Designed for cost-effective enterprise access scenarios, it features 24 Ethernet 10/100Base-TX ports, 2 Combo GE ports (RJ45/SFP), and a fixed built-in AC power supply. Engineered for reliable data switching, enhanced security, and QoS management, this model is ideal for small to mid-sized business networks, campus deployments, and branch offices.
Key Features
- Model: S2700-26TP-EI-AC
- Condition: 100% Brand New, Original Huawei
- Port Configuration: 24 × 10/100Base-TX + 2 × Combo GE (RJ45/SFP)
- Switching Capacity: 12.8 Gbps
- Forwarding Rate: 9.5 Mpps
- Power Supply: Built-in AC Power (1x AC)
- Layer Support: Layer 2 with enhanced management features
- Fanless Design: Quiet operation for office environments
- Energy-Efficient Ethernet (EEE): Reduces power consumption during low activity
Technical Specifications
| Specification | Details |
|---|---|
| Model | S2700-26TP-EI-AC |
| Switching Capacity | 12.8 Gbps |
| Forwarding Rate | 9.5 Mpps |
| Fixed Ports | 24 × 10/100Base-TX |
| Uplink Ports | 2 × Combo GE (10/100/1000 RJ45 or SFP) |
| MAC Address Table | 8K entries |
| VLANs | Supports up to 4K VLANs |
| Security Features | 802.1X, port security, storm control |
| QoS Features | 4 queues per port, WRR/SP scheduling |
| Dimensions (W×D×H) | 442 mm × 220 mm × 43.6 mm |
| Weight | ≤ 3.5 kg |
| Power Supply | Built-in 100–240V AC, 50/60Hz |
| Power Consumption | ≤ 20W |
| Operating Temperature | 0°C to 45°C |
| Humidity | 5% to 95% RH, non-condensing |
| Mounting | 1U Rack-mountable or desktop |
| Warranty | 1–3 Years Manufacturer Warranty |
Applications of S2700-26TP-EI-AC Huawei
- Enterprise Networks – Reliable Layer 2 access switching for wired workstations
- Branch Offices – Simplified deployments with combo uplinks to the core layer
- Campus Networks – Access switch for classrooms, labs, and offices
- Retail & SMB – Affordable Gigabit-ready backbone with enhanced security
- Surveillance Systems – Aggregates IP camera traffic with traffic control features
Customization & OEM Options
- Private Labeling – Custom logo and packaging for OEM/ODM clients
- Preset Configuration – VLAN and port policies configured before delivery
- Customized Bundles – Switch with transceivers, patch cables, rack ears
- Enhanced QA – Optional long-burn test cycles for industrial deployment
- Localized Firmware – Custom language or feature sets on request
Wholesale & Global Supply Info
- Direct Huawei OEM Stock – Genuine and traceable inventory
- Bulk Pricing Available – Discounts for integrators and resellers
- Fast Worldwide Delivery – Secure packaging for international shipping
- In-Stock Units – Immediate dispatch available for urgent projects
- After-Sales Support – Access to configuration support and technical documentation
Why Choose the S2700-26TP-EI-AC Huawei
Cost-Efficient Access – Ideal for growing enterprise and SME networks
Fanless & Silent – Perfect for quiet office spaces or retail shops
Reliable Performance – Supports high-volume packet forwarding
Secure & Manageable – Includes basic Layer 2 security & QoS features
Huawei Quality – Durable, stable, and energy efficient
Request a Quote or Technical Sheet Today
Contact us now for bulk pricing, datasheets, and stock availability on the Huawei S2700-26TP-EI-AC — the trusted solution for efficient, secure, and scalable enterprise network access.
