S5700-28C-EI-24S-AC Huawei Brand New 24-Port Gigabit Ethernet Switch
The S5700-28C-EI-24S-AC Huawei is a high-performance Layer 3 switch designed for enterprise campus networks, SMB aggregation, and secure departmental networking. With 24 Gigabit SFP ports and versatile uplink options, it delivers robust performance, flexible fiber connectivity, and enterprise-grade reliability.
Key Features
Model: S5700-28C-EI-24S-AC
Condition: 100% Brand New, Original Huawei
Switch Type: Layer 3 Managed Gigabit Ethernet Switch
Ports: 24 x 1000BASE-X SFP slots + multiple uplink options
Power Supply: Integrated 1 x AC Power Module for stable operation
Switching Capacity: Large forwarding capacity with advanced hardware architecture
Energy Efficient: Intelligent fan speed control, port power management, and low power consumption
Layer 3 Routing: Supports static routing, RIP, OSPF, and policy-based routing
Advanced Security: Comprehensive user access control, ACLs, DHCP snooping, ARP inspection, and port isolation
Management: CLI, SNMP, web-based GUI, and Huawei iManager NMS support
Reliability: Industrial-grade build quality, loop prevention, and fault detection
Tech Specs
| Item | Specification |
|---|---|
| Fixed Ports | 24× Gigabit SFP ports, 4 of which are dual-purpose 10/100/1000Base-T or SFP ports |
| Forwarding Performance | 96 Mpps |
| Extended Slots | 2: 1 for uplink subcard, 1 for stack card |
| MAC Address Table | IEEE 802.1d compliant, 32K MAC addresses, supports learning, aging, static/dynamic/blackhole entries, filtering based on source MAC |
| VLAN | 4K VLANs, Guest/Voice VLAN, VLAN assignment by MAC/protocol/IP/port, GVRP, MUX VLAN, SuperVLAN |
| Reliability | RRPP, Smart Link, SEP, ERPS (G.8032), STP/RSTP/MSTP, BPDU/root/loop protection, E-Trunk, BFD for OSPF/IS-IS/VRRP/PIM |
| IP Routing | Static, RIP v1/v2/RIPng, ECMP, OSPF/OSPFv3/IS-IS/IS-ISv6/BGP/BGP4+ (EI/HI series only) |
| IPv6 Features | ND, PMTU, IPv6 ping/tracert/Telnet, ACLs, MLD v1/v2 snooping, 6to4, ISATAP, manual tunnels |
| Multicast | IGMP v1/v2/v3 snooping, IGMP fast leave, PIM-SM/DM/SSM, MSDP (EI/HI), controllable multicast, port-based stats |
| QoS/ACL | 8 queues per port, SP, WRR, DRR, SP+WRR, DRR+SP, WRED (EI/HI), re-marking, port shaping, L2–L4 filtering, CAR |
| Security | User privileges, password protection, DoS/ARP/ICMP defense, port isolation/security/sticky MAC, MFF, 802.1x, AAA, RADIUS, HWTACACS, NAC, SSH v2.0, HTTPS, CPU defense, black/whitelist |
| OAM | Supported |
| Access Security | DHCP Relay, DHCP Server, DHCP Snooping, DHCP Security |
| Management | Virtual cable test, stacking, MFF, port mirroring/RSPAN, Telnet, SNMP v1/v2/v3, RMON, Web NMS, HGMP, logs/alarms, 802.3az EEE (LI/EI/HI), NetStream (EI/HI), sFlow (LI/EI/HI) |
| Interoperability | VBST (PVST compatible), LNP (like DTP), VCMP (like VTP) |
| Memory | DDR: 256 MB; Flash: 32 MB |
| MTBF | 52.8 years (no card), 41.33 years (2×10GE card), 50 years (4×GE front card), 26.52 years (4×10GE front card) |
| MTTR | 2 hours |
| Availability | > 0.99999 |
| Surge Protection (Ports) | ±2 kV common mode (non-PoE) |
| Surge Protection (Power) | AC: ±6 kV diff/common; DC: ±1 kV diff / ±2 kV common |
| Stack Ports | 2 per stack card |
| Max Stack Bandwidth | 48 Gbit/s (bidirectional) |
| RPS | Not supported |
| PoE | Supported on PWR series |
| Input Voltage (DC) | Rated: -48 V DC to -60 V DC; Max: -36 V DC to -72 V DC |
| Input Voltage (AC) | Rated: 100–240 V AC, 50/60 Hz; Max: 90–264 V AC, 47–63 Hz |
| Max Power Consumption | 63 W (100% throughput, PoE load, full fan speed) |
| Operating Temperature | 0°C to 50°C |
| Storage Temperature | –40°C to +70°C |
| Noise @ 27°C | < 41 dBA |
| Humidity | 5%–95% RH (non-condensing) |
| Altitude | Non-PoE: AC 0–5000 m; DC 0–2000 m; PoE: 0–5000 m |
| EMC Compliance | CISPR22/24, EN55022/EN50024, FCC Part 15 Class A, ICES 003 Class A, AS/NZS CISPR22 Class A, IEC61000-4-2, ITU-T K 20/K 44 |
| Environmental | RoHS, REACH, WEEE |
| Safety | IEC 60950-1, UL 60950-1, CSA C22.2, AS/NZS 60950.1 |
| Laser Safety | IEC/EN60825-1/2 |
| Dimensions (W × D × H) | 442.0 mm × 420.0 mm × 43.6 mm |
| Weight (Fully Loaded) | ≤ 8.5 kg |
| Weight (Empty) | ≤ 5 kg |
S5700-28C-EI-24S-AC Huawei Applications
The S5700-28C-EI-24S-AC is perfect for:
• Enterprise Campus Access: High-speed fiber connectivity for desktops, IP phones, and wireless APs
• SMB Core or Aggregation: Flexible uplinks for small data centers and campus backbones
• Branch Office Networks: Secure Layer 3 routing and VLAN management for distributed sites
• Departmental Networks: Segmented access and robust user control for sensitive environments
• Industrial & Commercial: Rugged design for reliable operation in diverse conditions
Customization & OEM Services
Value-added services include:
• Pre-Configuration: VLAN, QoS, and routing setup for out-of-the-box deployment
• OEM Branding: Custom labeling and packaging for system integrators and resellers
• Project Bundling: Full site kitting with modules, transceivers, and accessories
• Enhanced Burn-In Testing: Ensures stability for mission-critical installations
S5700-28C-EI-24S-AC Huawei Wholesale & Bulk Procurement
Why choose us:
• Factory Pricing: Competitive discounts for wholesale and project orders
• Global Fulfillment: Secure packaging and rapid international shipping
• Dedicated Account Managers: Personalized support for planning and rollouts
• Consistent Stock Availability: Reliable supply for large-scale installations
• Official Huawei Warranty: Full technical support and warranty coverage for peace of mind
S5700-28C-EI-24S-AC Huawei Why Choose Us
100% Original Huawei Equipment — Fully tested and certified
Flexible OEM Options — Tailored solutions for your branding and technical requirements
Competitive Wholesale Rates — Ideal for VARs, system integrators, and enterprise customers
Professional Logistics — Safe, efficient global delivery
Expert Technical Support — Assistance from design to deployment and maintenance
Contact Us for the Best Pricing
Upgrade your network with the S5700-28C-EI-24S-AC Huawei Brand New Switch — the ideal balance of performance, security, and efficiency for modern fiber-centric enterprise environments.
