S5700S-28P-PWR-LI-AC Huawei Brand New 24-Ports Power Module
The S5700S-28P-PWR-LI-AC Huawei is a high-performance, PoE-enabled Layer 3 Ethernet switch designed for enterprise-class campus networks and intelligent PoE deployments. It features 24 Ethernet 10/100/1000 PoE+ ports, 4 Gig SFP uplink ports, and an integrated AC power module, making it an efficient and scalable solution for powering access points, IP phones, and surveillance devices in converged networks.
This brand-new Huawei switch supports full IEEE 802.3af/at PoE standards, offering intelligent power management, advanced Layer 2/3 switching capabilities, and enhanced security features—ideal for energy-saving, high-density, and flexible networking infrastructures.
Key Features
Model: S5700S-28P-PWR-LI-AC
Condition: 100% Brand New, Original Huawei
Ports: 24 × 10/100/1000Base-T PoE+ ports, 4 × 1000Base-X SFP ports
PoE Standard: IEEE 802.3af (PoE), IEEE 802.3at (PoE+)
Power Module: Built-in AC power supply
Switching Capacity: 128 Gbps
Forwarding Performance: 42 Mpps
MAC Address Table: 16K entries
Layer 3 Routing: Static routes, RIP, OSPF, VRRP (basic)
Energy Efficiency: Intelligent PoE scheduling, port-based power control
Security Features: Port isolation, DHCP snooping, MAC filtering, AAA
Reliability: Fanless or low-noise design with over-temperature protection
Installation: 1U rack mountable with plug-and-play operation
Stacking Capability: iStack support (up to 9 devices)
Technical Specifications
| Specification | Details |
|---|---|
| Model | S5700S-28P-PWR-LI-AC |
| Type | L3 GE PoE Switch with AC Power |
| PoE Ports | 24 × GE Base-T PoE+ (IEEE 802.3af/at) |
| Uplink Ports | 4 × GE SFP |
| PoE Power Budget | 370W (typical, varies by AC model) |
| Forwarding Rate | 42 Mpps |
| Switching Capacity | 128 Gbps |
| Max MAC Address Table | 16K |
| Power Supply | AC built-in |
| Operating Temperature | 0°C to +50°C |
| Storage Temperature | -40°C to +70°C |
| Relative Humidity | 5% to 95% (non-condensing) |
| Dimensions (W×D×H) | 442 mm × 220 mm × 43.6 mm (1U standard) |
| Weight | Approx. 4.3 kg |
| MTBF | >200,000 hours |
| Compliance | IEEE, CE, RoHS, REACH, WEEE |
| Warranty | 1–3 Years Manufacturer Warranty |
S5700S-28P-PWR-LI-AC Huawei Applications
- Enterprise Campus Networks — Power and data transmission for access points, IP phones, and surveillance cameras
- Smart Office Infrastructure — Intelligent PoE scheduling to reduce energy costs
- Education and Healthcare Networks — Simplified management and high network uptime
- Retail Chains & Branch Offices — Compact, high-performance switches with plug-and-play deployment
- Hotel & Hospitality — Reliable and silent operation for guest-facing areas
Customization & OEM Options
Private Labeling — Custom branding with your company logo and labeling for global OEM projects
Pre-Configuration Service — VLANs, QoS policies, port settings, and security pre-set before shipment
PoE Budget Customization — Optional upgrades for higher PoE power budget configurations
Region-Specific Power Supply — Tailored for different power standards (EU/US/UK/AU)
Temperature-Hardened Models — Optional conformal coating or industrial-grade temperature versions for harsh environments
Accessories Kit — Custom rack-mount brackets, SFP module bundles, and patch cables
S5700S-28P-PWR-LI-AC Huawei Wholesale & Global Procurement
Bulk Purchase Pricing — Competitive OEM-level discounts for volume orders
Direct Huawei Factory Supply — Verified original stock with full warranty
Safe International Packaging — Double-layer foam and anti-static box packaging
Fast Dispatch & Delivery — Same-day shipping available for in-stock units
Global Compliance — CE, FCC, RoHS certification and international logistics-ready
Technical Integration Support — Remote configuration guidance, firmware updates, and RMA services
Why Choose S5700S-28P-PWR-LI-AC Huawei 24-Port PoE Switch
- Full PoE+ Support — Delivers up to 30W per port, ideal for high-power devices
- Advanced L2/L3 Features — Routing, security, QoS, and multicast built-in
- Huawei Reliability — Proven long-term stability in mission-critical networks
- Integrated Power Supply — Saves rack space and simplifies deployment
- Low Power & Silent Design — Energy-efficient operation with smart cooling
- Scalable Deployment — Stackable and easy to integrate into growing networks
Contact Us for Datasheets, Pricing & OEM Partnership
Ready to scale your enterprise or telecom network with Huawei’s S5700S-28P-PWR-LI-AC? Contact us now to receive a quote, product datasheets, and information on volume discounts, OEM services, and integration support.
