S5720-32P-EI-AC Huawei Brand New 4-Port Switch with 1 AC Power Fixed
The Huawei S5720-32P-EI-AC is a brand new, high-performance Layer 3 Ethernet switch designed for enterprise campus networks, ISP access, and carrier-grade business scenarios. This flexible and reliable switch combines robust forwarding capabilities with advanced security and energy-saving features — ensuring stable and secure access for medium and large-scale network deployments.
Equipped with 32 Ethernet ports, enhanced Layer 3 routing, and 1 fixed AC power supply, the S5720-32P-EI-AC is the ideal choice for building scalable, high-density network cores and distribution layers.
Key Features
-
Model: S5720-32P-EI-AC
-
Condition: 100% Brand New, Original Huawei
-
Ports:
-
24 × 10/100/1000Base-T Ethernet ports
-
4 × GE SFP uplink ports
-
4 × Combo GE SFP/Ethernet ports (model-dependent)
-
-
Power Supply: 1 fixed AC power module, designed for stable operation and energy efficiency
-
Layer 3 Capabilities: Supports static routing, RIP, OSPF, and BGP for advanced network topologies
-
Security: Comprehensive features including MAC address learning limit, DHCP snooping, ARP security, and 802.1x authentication
-
Energy Saving: Innovative Energy Efficient Ethernet (EEE) for lower power consumption
-
Reliability: Carrier-grade hardware with hot-swappable fan modules and robust surge protection
-
Management: Easy configuration and management via CLI, SNMP, RMON, and web-based GUI
-
Compatibility: Fully interoperable with Huawei CloudEngine and other network devices
Tech Specs
| Item | Description |
|---|---|
| Fixed Ports | 24 × 1000BASE-T, 4 × FE/GE SFP, 4 × GE SFP |
| Memory (RAM) | 2 GB |
| Flash | 512 MB total |
| MTBF | 80.32 years |
| MTTR | 2 hours |
| Availability | > 0.99999 |
| Service Port Surge Protection | Common mode: ±6 kV |
| Power Supply Surge Protection | ±6 kV differential mode, ±6 kV common mode |
| Dimensions (H × W × D) | Basic: 43.6 × 442.0 × 224.9 mm Max: 43.6 × 442.0 × 237.3 mm |
| Weight (with packaging) | 4.5 kg (9.92 lb) |
| Stack Ports | Two fixed QSFP+ stack ports on rear card |
| RTC | Supported |
| RPS | Supported |
| PoE | Not supported |
| Rated Voltage Range | 100 V AC to 240 V AC, 50/60 Hz |
| Maximum Voltage Range | 90 V AC to 264 V AC, 47 Hz to 63 Hz |
| Maximum Power Consumption | 50.7 W (100% throughput, full fan speed) |
| Typical Power Consumption | 39.75 W (30% traffic load) |
| EEE | Enabled |
| Operating Temperature | 0°C to 45°C (32°F to 113°F) at 0–1800 m (0–5906 ft) |
| Storage Temperature | -40°C to +70°C (-40°F to +158°F) |
| Noise at Normal Temp. (27°C) | < 49.3 dB(A) |
| Relative Humidity | 5% to 95% (non-condensing) |
| Operating Altitude | 0–5000 m (0–16404 ft) |
| Certification | EMC, Safety, Manufacturing certifications |
| Part Number | 02350BDY |
S5720-32P-EI-AC Applications
The S5720-32P-EI-AC Huawei Switch is widely deployed for:
• Enterprise campus access and aggregation layers
• ISP and carrier network edge
• Government, education, and hospitality networks
• SMEs requiring stable Layer 3 routing and switching
• Remote branch sites needing flexible, secure connectivity
Customization & OEM Services
We offer flexible customization and OEM services for the S5720-32P-EI-AC, including:
• Pre-configuration and VLAN setup for plug-and-play deployment
• Private labeling and packaging for system integrators and resellers
• Bundling with transceivers, patch cords, and mounting accessories
• Custom burn-in and testing for mission-critical use cases
S5720-32P-EI-AC Wholesale & Bulk Orders
Source the S5720-32P-EI-AC Huawei Switch directly from us for large-scale rollouts and wholesale supply:
• Factory-direct pricing with attractive volume discounts
• Ample stock availability for urgent projects
• Secure, export-compliant packaging to prevent transit damage
• Global shipping with trusted logistics partners
• Dedicated account managers for multi-site deployments
• Full technical support and warranty for hassle-free operation
S5720-32P-EI-AC Why Choose Us
100% Original Huawei Hardware, fully certified and tested
Flexible Configurations & OEM Options
Competitive Wholesale Pricing for enterprise, ISP, and public sector projects
Fast, Reliable Global Logistics
Expert Technical Support from pre-sales through deployment
Contact Us for a Quote
Upgrade your network’s performance and reliability with the Huawei S5720-32P-EI-AC Layer 3 Ethernet Switch — your trusted solution for stable, secure, and cost-effective network expansion.
