S5720-32X-EI-DC Huawei Brand New 10GE SFP+, 1 DC Power Fixed
The S5720-32X-EI-DC Huawei Switch is an original, high-performance Gigabit Ethernet switch designed for next-generation enterprise campus, data center access, and high-density aggregation scenarios. This model comes with 32 fixed 10GE SFP+ ports and features a built-in DC power supply, providing flexible, cost-effective, and energy-efficient connectivity for demanding network environments.
Part of Huawei’s S5700 series, the S5720-32X-EI-DC combines advanced hardware architecture, carrier-class reliability, and rich Layer 2/Layer 3 features to ensure stable, secure, and scalable network operations. Its compact design, hot-swappable fan modules, and intelligent O&M tools make it ideal for enterprises, ISPs, and data centers looking to modernize their network infrastructure.
Key Features
-
Model: S5720-32X-EI-DC
-
Condition: 100% Original, Brand New Huawei
-
Ports: 32 x 10GE SFP+ fixed ports
-
Power Supply: Built-in DC power module for stable operation in DC-powered environments
-
Performance: High forwarding performance with advanced switching capacity
-
Layer 2/3 Features: Comprehensive VLAN, QoS, ACL, and routing capabilities
-
Reliability: Carrier-grade hardware design with redundant fan modules
-
Energy Efficiency: Intelligent power-saving technology reduces OPEX
-
Management: Supports SNMP, CLI, web-based management, and cloud O&M
-
Compatibility: Fully integrates with Huawei’s Agile Campus and CloudFabric solutions
Tech Specs
Interfaces & Performance
| Item | Description |
|---|---|
| Fixed Ports | 24 × Ethernet 10/100/1000 Mbps ports 4 × 100/1000 SFP 4 × 10G SFP+ 2 × QSFP+ dedicated stack ports |
| Forwarding Performance | 102 Mpps |
| Extended Slots | Not Applicable |
| DRAM and Flash | SDRAM: 2 GB; Flash: 340 MB |
Layer 2 Features
| Item | Description |
|---|---|
| MAC Address Table | IEEE 802.1d 64K MAC entries Learning & aging Static, dynamic, blackhole entries Source MAC filtering |
| VLAN | Up to 4K VLANs Guest VLAN, Voice VLAN GVRP, MUX VLAN VLAN assignment: MAC, protocol, IP subnet, policy, port 1:1 & N:1 mapping VLAN-based protocol transparency |
| Jumbo Frame | 12K bytes |
| Ring Protection | RRPP, Smart Link, SEP, G.8032 ERPS STP (802.1d), RSTP (802.1w), MSTP (802.1s) BPDU/root/loop protection, BPDU tunnel |
IP Routing
| Item | Description |
|---|---|
| Routing Protocols | Static routing, RIPv1/2, RIPng, OSPF/OSPFv3, IS-IS/IS-ISv6, BGP/BGP4+, ECMP, policy-based routing |
| Routing Capacity | 16K IPv4 unicast, 8K IPv6 unicast routes 3K IPv4 static, 1K IPv6 static routes |
| IPv6 Features | ND, PMTU, IPv6 Ping/Tracert/Telnet, 6to4, ISATAP, manual tunnels, ACLs, MLD v1/v2 snooping |
Multicast
| Item | Description |
|---|---|
| Multicast Forwarding | IGMP v1/v2/v3 snooping, fast leave, intra/inter-VLAN forwarding, trunk load splitting, controllable multicast, port-based multicast stats, IGMP, PIM-SM, PIM-DM, PIM-SSM, MSDP |
QoS & ACL
| Item | Description |
|---|---|
| Traffic Management | Port rate limiting (in/out), packet redirection, broadcast storm control, policing, CAR, 8 queues per port, WRR/DRR/SP scheduling, WRED, re-marking, per queue shaping |
| ACLs | L2–L4 filtering: MAC/IP, TCP/UDP ports, VLAN IDs, protocols |
| Mirroring | 1:1, N:1, N:4 port/VLAN mirroring |
Security
| Item | Description |
|---|---|
| Access Control | Hierarchical user management, password protection, DoS/ARP/ICMP defense, IP-MAC-Interface-VLAN binding, port isolation/security/sticky MAC, MFF, blackhole MAC, MAC limits |
| Authentication | IEEE 802.1x, user limits, AAA, RADIUS, HWTACACS+, NAC, SSH v2.0, HTTPS, CPU defense, black/white lists, MACSec ready |
| DHCP Security | DHCP Relay, Server, Snooping, Client, Security |
Link Aggregation
| Item | Description |
|---|---|
| Port Aggregation | LACP, up to 128 trunks, max 8 members per trunk |
Reliability
| Item | Description |
|---|---|
| OAM & BFD | Ethernet OAM (802.3ah, 802.1ag), ITU-Y.1731, BFD for BGP/IS-IS/OSPF/static routes |
Super Virtual Fabric (SVF)
| Item | Description |
|---|---|
| SVF | Acts as plug-and-play SVF client, auto software loading, one-click config delivery, supports independent client mode |
Management & Maintenance
| Item | Description |
|---|---|
| Tools & Protocols | iStack, virtual cable test, SNMP v1/v2c/v3, RMON/RMON2, web NMS, logs & alarms, sFlow, LLDP/LLDP-MED, 802.3az EEE, SCP, TFTP, FTP, dual images/configs |
| Interoperability | VLAN STP (PVST/PVST+/RPVST), LNP (like DTP), VCMP (like VTP) |
S5720-32X-EI-DC Huawei Environmental
| Item | Description |
|---|---|
| Operating Temperature | 0–45℃ (0–1800 m altitude) 1800–5000 m: reduce by 1℃ every 220 m |
| Humidity | 5% to 95% RH (non-condensing) |
| Input Voltage | AC: 100–240 V AC, 50/60 Hz (rated); 90–264 V AC, 47/63 Hz (max) |
| Power Consumption | Typical: 40.9 W |
| Dimensions (mm) | 442 (W) × 220 (D) × 43.6 (H) |
S5720-32X-EI-DC Huawei Applications
The S5720-32X-EI-DC Huawei Switch is ideal for:
• Enterprise campus networks providing high-speed server or uplink access
• Data center access layers with dense 10GE server connections
• Carrier metro and aggregation networks requiring stable 10GE links
• Industrial and power facilities where DC power supply is a must
• SMEs and service providers upgrading to high-performance 10GE switching
S5720-32X-EI-DC Huawei Customization & OEM Services
We offer flexible customization and OEM services for the S5720-32X-EI-DC:
• Pre-configuration of VLANs, routing protocols, and access policies
• Private labeling and custom branding for resellers and integrators
• Custom packaging for bulk orders and distributed site deployments
• Extended burn-in testing for mission-critical deployments
• Firmware and software tailoring to match your network requirements
S5720-32X-EI-DC Huawei Wholesale & Bulk Orders
Source the S5720-32X-EI-DC Switch directly from us for wholesale supply and bulk procurement:
• Factory-direct pricing with competitive volume discounts
• Consistent inventory to support large rollouts and project needs
• Secure export-compliant packaging to ensure safe global delivery
• Dedicated account managers to coordinate large-scale deployments
• Full technical support & warranty for maximum peace of mind
S5720-32X-EI-DC Huawei Why Choose Us
100% Original Huawei Hardware — Certified, tested, and ready to deploy
Flexible Customization — Solutions that match your unique site needs
Competitive Wholesale Pricing — Ideal for enterprises, data centers, and ISPs
Secure Global Logistics — Trusted, export-compliant shipping worldwide
Expert Technical Support — From planning and configuration to after-sales service
Contact Us for a Quote
Upgrade your network’s capacity with the S5720-32X-EI-DC Huawei Brand New 10GE SFP+ Switch — the perfect solution for energy-efficient, high-density 10GE connectivity.
