S5720S-52X-PWR-LI-AC Huawei Brand New 48-Ports Power Fixed Ethernet Switch
The S5720S-52X-PWR-LI-AC Huawei is a high-performance Layer 3 Lite switch equipped with 48 Gigabit Ethernet PoE ports and 4 10 Gigabit SFP+ uplink ports, delivering exceptional access capabilities for enterprise campus networks and IP surveillance systems. With advanced PoE support, efficient energy-saving design, and reliable hardware performance, it offers seamless power and data delivery for high-density access environments.
Key Features
Model: S5720S-52X-PWR-LI-AC
Condition: 100% Brand New, Original Huawei
Port Configuration: 48 × 10/100/1000BASE-T (PoE) + 4 × 10GE SFP+
PoE Capability: IEEE 802.3af/at compliant
Switching Capacity: 336 Gbps
Forwarding Performance: 96 Mpps
Power Supply: Built-in AC power supply
Layer Support: Layer 2 and basic Layer 3 features
Cooling System: Smart fans with temperature control
Security Features: 802.1X, DHCP snooping, MAC filtering, ACLs
Management Interfaces: SNMP, CLI, Web GUI, RMON
Installation: Rack-mountable 1U chassis
Technical Specifications
| Specification | Details |
|---|---|
| Model | S5720S-52X-PWR-LI-AC |
| Ports | 48 × GE RJ45 PoE + 4 × 10GE SFP+ uplinks |
| Switching Capacity | 336 Gbps |
| Forwarding Rate | 96 Mpps |
| PoE Standard | IEEE 802.3af/at (PoE/PoE+) |
| Max PoE Power Budget | 370W |
| MAC Address Table | 32K entries |
| Layer Features | Static routing, VLAN, STP, MSTP, IGMP |
| Power Supply | Built-in AC (100V–240V, 50/60Hz) |
| Power Consumption | ≤ 450W (full PoE load) |
| Operating Temperature | 0°C to +50°C |
| Storage Temperature | -40°C to +70°C |
| Relative Humidity | 5%–95% (non-condensing) |
| Dimensions (WxDxH) | 442 × 420 × 43.6 mm |
| Weight | Approx. 5.8 kg |
| Warranty | 1–3 Years Manufacturer Warranty |
S5720S-52X-PWR-LI-AC Huawei Applications
-
Enterprise Access Layer – Ideal for powering IP phones, APs, and endpoints
-
Smart Building Infrastructure – Combines PoE power and data for efficient wiring
-
IP Surveillance Networks – Simplifies deployment of HD PoE cameras
-
Educational Institutions – Supports secure access with high performance
-
Branch Office Networks – Cost-effective Layer 3 lite solution with 10G uplinks
Customization & OEM Options
-
Private Labeling – Brand the device with your logo or model ID
-
Preconfigured Settings – VLANs, QoS rules, security policies pre-installed
-
Localized Accessories – Power cords (EU/UK/US/CN) and rack kits per region
-
Firmware Configuration – Customized OS version based on deployment needs
-
Bulk Packaging – Cost-saving carton or foam-pack options for large orders
Wholesale & Global Supply Information
-
Bulk Stock Ready – Available for global distribution and urgent rollouts
-
Competitive Pricing – Direct-from-factory rates for MSPs and integrators
-
Fast Shipping Worldwide – Shipped via DHL/FedEx/UPS with tracking
-
Quality Assurance – 100% brand new, sealed, and factory-tested
-
Technical Support – Remote guidance for setup, integration & NMS compatibility
-
Safe Packaging – ESD protection and reinforced cartons for export compliance
Why Choose the S5720S-52X-PWR-LI-AC Huawei Switch
-
48 Full Gigabit PoE Ports – Simplify cabling with integrated power and data
-
10G Uplinks – Ensure high-speed backbone connectivity
-
Huawei OEM Reliability – Trusted performance in commercial environments
-
Energy-Efficient – Smart fans and power-saving features reduce OPEX
-
Scalable & Secure – Perfect for fast-growing enterprise networks
Contact Us for Pricing, Lead Time & OEM Requests
Deploy high-performance access solutions with the Huawei S5720S-52X-PWR-LI-AC switch.
Request a quote now for wholesale pricing, customization details, or technical documentation.
