SC/UPC 1×64 Pigtail Brand New Type Optical Fiber Splitter
The SC/UPC 1×64 Pigtail Fiber Splitter is a high-precision passive optical device used for splitting a single optical signal into 64 output channels with excellent uniformity and low insertion loss. Designed for FTTH, FTTx, PON, CATV, and other high-density fiber distribution networks, this splitter ensures stable signal transmission across a wide wavelength range.
Built with a pigtail design, this type is easy to splice directly into fiber trays, outdoor closures, or ODFs, making it an ideal solution for space-saving, flexible deployments in both indoor and outdoor environments.
Key Features
-
Splitter Type: 1×64 PLC (Planar Lightwave Circuit) Splitter
-
Design: Pigtail version for easy splicing and flexible installation
-
Connector Type: SC/UPC connectors on each fiber for plug-and-play connections
-
Operating Wavelength: 1260~1650nm — fully compatible with EPON, GPON, XG-PON, and other PON systems
-
Low Insertion Loss: Maintains signal quality over multiple splits
-
High Uniformity: Even power distribution among all output channels
-
Durable Build: Complies with Telcordia GR-1209 and GR-1221 for reliability
-
Condition: 100% Brand New and factory tested
Technical Specifications
| Category | Specification |
|---|---|
| Splitter Type | PLC (Planar Lightwave Circuit) |
| Configuration | 1×64 |
| Fiber Type | Singlemode |
| Connector Type | SC/UPC |
| Operating Wavelength | 1260–1650nm |
| Insertion Loss | ≤ 21.5 dB |
| Uniformity | ≤ 2.0 dB |
| Return Loss | ≥ 55 dB |
| Polarization Dependent Loss (PDL) | ≤ 0.3 dB |
| Directivity | ≥ 55 dB |
| Operating Temperature | -40°C to +85°C |
| Compliance | Telcordia GR-1209, GR-1221, RoHS |
SC/UPC 1×64 Pigtail Applications
FTTH/FTTx Deployments: Connects up to 64 subscribers from a single input fiber
PON Networks: Ideal for EPON, GPON, XG-PON systems
CATV Systems: Splits optical RF signals for multi-point distribution
Optical Test Systems: Suitable for lab environments requiring multi-port signal splitting
High-Density Installations: Space-efficient for ODFs, distribution frames, and outdoor closures
Customization & OEM Services
Custom Pigtail Lengths: Input and output fiber lengths can be tailored to your project needs
Connector Options: SC/APC, LC/UPC, LC/APC, or FC/UPC available on request
OEM Branding: Private label and custom packaging services for distributors and system integrators
Pre-Termination: Pre-terminated with protective tube or fan-out kit if needed
Factory Test Reports: Insertion loss and uniformity reports included
SC/UPC 1×64 Pigtail Wholesale & Bulk Procurement
Competitive Factory Pricing: Save more with bulk orders for rollouts and upgrades
Secure Global Fulfillment: Export packaging designed to protect delicate fibers
Dedicated Project Support: Professional account managers to assist with specifications and logistics
Warranty Included: 100% original, brand new, and backed by a reliable warranty
SC/UPC 1×64 Pigtail Why Choose Us
Genuine & Fully Certified Optical Splitters
Flexible Configurations & Fast Customization
Attractive Wholesale Rates for ISPs, Installers & VARs
Safe, Worldwide Shipping
Expert Technical & After-Sales Support
Contact Us for Best Pricing
Expand your fiber network capacity with the SC/UPC 1×64 Pigtail Brand New Type Optical Fiber Splitter — a trusted solution for high-density, cost-effective signal distribution in modern fiber access networks.
