- Model Number:HT-PES801G
- Country of Origin:Guangdong, China
- Brand:OEM
- Application:Support PoE IP cameras/IP phones/WIFI AP
- Port:2* 10/100/1000 Mbps RJ45
- Input Voltage:AC 100-240V 50/60Hz
- PoE Standard:IEEE802.3af/at
- Power:30W
- Output:52V
- Power Supply Pin:1,2+/3,6-
- Data Pin:1,2/3,6
- Features:Plug and play
- System reliability:MTBF> 100k hours
- Warranty:12 Months
- Selling Units:Single item
- Single package size: 12.5X6.5X4.5 cm
- Single gross weight:0.350 kg
- Package Type:Neutral gift box
- Lead time:Quantity(pieces)1 – 12 – 100101 – 2000>2000Lead time (days)3725To be negotiated
Feature
1. Comply to IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, 802.3X, 802.3z.
2.Comply to PoE IEEE 802.3af/at standard, all ports standard testing.
3.Support PoE IP cameras, PoE WIFI AP, and PoE IP phones
4.2*10/100/1000 Mbps RJ45
5.Upstream port lightning protection.
6.30W Power output
7.Power transmission distance:100M
2.Comply to PoE IEEE 802.3af/at standard, all ports standard testing.
3.Support PoE IP cameras, PoE WIFI AP, and PoE IP phones
4.2*10/100/1000 Mbps RJ45
5.Upstream port lightning protection.
6.30W Power output
7.Power transmission distance:100M
Products Description
|
Model
|
PSE801G
|
|
Power Supply Pin
|
1,2+/3,6-
|
|
Output
|
52V
|
|
Power
|
30W
|
|
PoE Standard
|
IEEE802.3af/at
|
|
Data Pin
|
1,2/3,6
|
|
Input
|
AC 100-240V 50/60Hz
|
|
Port
|
2* 10/100/1000 Mbps RJ45
|
|
Features
|
Plug and play, no configuration management functions Power supply has input overvoltage, output overvoltage, output over current
short circuit protection and other functions. System reliability: MTBF> 100k hours. |
|
Environmental
|
Working Temperature: -25℃~65℃
Storage temperature: -40℃~70℃ Working Humidity: 10%~90% RH non-condensing Storage Humidity: 5%~90% RH non-condensing |
|
Speed |
Ethernet 10Mbps half-duplex, 20Mbps full-duplex
Fast Ethernet 100Mbpshalf-duplex, 200Mbps full-duplex Gigabit Ethernet 2000Mbps full-duplex |
|
Network Media |
10Base-T: Pair 2 Category 3(Cat3) and above UTP/STP(≤150m)
100Base-TX: Pair 2 Category 5(Cat5) and above UTP/STP(≤150m) 1000Base-T: Pair 4 Category 5(Cat6) and above UTP/STP(≤150m) |
