SS64S16A(L-16.1,SC) Huawei Brand New 2.5G Optical Interface Board
The SS64S16A(L-16.1,SC) Huawei is a high-performance 2.5G optical interface board engineered for STM-16 (SDH) transmission in Huawei’s OSN series transmission platforms. Equipped with a single long-haul L-16.1 SC optical interface, this board is optimized for delivering high-capacity optical services across distances of up to 40 kilometers over single-mode fiber (SMF).
This interface board is ideal for metro and core networks requiring reliable, long-distance SDH transmission with low power consumption and superior integration within Huawei’s hybrid transport systems.
Key Features
- Model: SS64S16A(L-16.1,SC)
- Condition: 100% Brand New, Original Huawei OEM
- Service Type: STM-16 (2.5 Gbps)
- Port Count: 1 Optical Port
- Connector Type: SC
- Transmission Distance: Up to 40 km (Single-Mode Fiber)
- Wavelength: 1550 nm
- Hot-Pluggable: Yes
- OSN Platform Compatibility: OSN 1500/2500/3500/7500 series
- Laser Class: Class 1 Compliant, Cooled DFB
- Performance Monitoring: Supported via Huawei NMS
Technical Specifications
| Specification | Details |
|---|---|
| Model | SS64S16A(L-16.1,SC) |
| Service Type | SDH STM-16 |
| Bit Rate | 2.488 Gbps |
| Connector Interface | SC |
| Fiber Type | Single-Mode (G.652) |
| Transmission Distance | 40 km (typical) |
| Wavelength | 1550 nm |
| Optical Output Power | -5 to 0 dBm |
| Receiver Sensitivity | ≤ -28 dBm |
| Laser Type | Cooled DFB Laser |
| DDM/DOM | Supported |
| Operating Temperature | -5°C to +45°C |
| Storage Temperature | -40°C to +70°C |
| Power Consumption | ≤ 15W |
| Compliance | ITU-T G.707, G.957, RoHS, CE, FCC |
SS64S16A(L-16.1,SC) Huawei Applications
- Telecom Backbone Networks — Long-distance SDH service transport
- Metro Access & Aggregation — High-capacity STM-16 connections
- Power Utilities & Transportation — Reliable synchronous transmission
- Government & Defense Networks — Secure long-haul optical connectivity
- Enterprise WANs — High-speed point-to-point fiber backbone links
Customization & OEM Options
- Private Labeling — Apply your brand/logo on request
- Extended Temperature Versions — Available for harsh environments
- Packaging Options — Bulk, retail, or integration-ready kits
- Compliance Tailoring — Country-specific certifications (CE, FCC, etc.)
- Factory Test Reports — Available upon bulk or contract orders
Wholesale & Global Supply Information
- Genuine Huawei Board — Sourced from certified OEM stock
- Global Distribution — Export-compliant packaging and logistics
- Bulk Availability — Sufficient inventory for ISPs and integrators
- Discount Tiers — Price reductions for volume purchases
- Deployment Support — Assistance for NMS configuration and port mapping
Why Choose the SS64S16A(L-16.1,SC) Huawei
Long-Haul 2.5G STM-16 Optical Interface
SC Connector with Industry-Standard 1550 nm Wavelength
Huawei OEM Quality for OSN Platforms
Reliable in Core and Metro SDH Environments
Integrated with Huawei U2000 Network Management System
Request a Quote or Technical Documentation
Enhance your SDH optical transport layer with the Huawei SS64S16A(L-16.1,SC) — a proven solution for long-range, high-bandwidth connectivity in mission-critical applications.
Contact us now for pricing, lead time, OEM options, and global shipping availability.
