TNF1LSCT75 Huawei Brand New Wavelength Conversion Board
The TNF1LSCT75 Huawei is a high-performance wavelength conversion board designed for Huawei’s DWDM optical transport systems. As part of the OptiX OSN series, this board enables the conversion of client-side signals into specific DWDM wavelengths, ensuring seamless integration into dense wavelength division multiplexing (DWDM) networks. With built-in 2.5G optical interfaces, the TNF1LSCT75 supports long-haul transmission with high stability and low attenuation.
This board is ideal for telecom operators and enterprise networks seeking to expand their optical layer transmission capacity without extensive fiber deployment.
Key Features
- Model: TNF1LSCT75
- Function: Wavelength conversion board (2.5 Gbit/s)
- Wavelength Support: 75th wavelength (per ITU-T grid)
- Client-side Interface: Optical, 2.5 Gbit/s
- Line-side Interface: DWDM, fixed 75th wavelength
- Transmission Distance: Long-haul, fiber dependent
- Hot-swappable: Yes
- Compatibility: Huawei OSN 1800/6800/8800 series
- Applications: Metro and core DWDM optical networks
Technical Specifications
| Specification | Details |
|---|---|
| Model | TNF1LSCT75 |
| Board Type | Wavelength conversion board |
| Service Type | OTN/SDH/2.5G services |
| Client Interface Rate | 2.5 Gbit/s |
| Line Interface | Fixed DWDM (75th wavelength, C-band) |
| Wavelength Grid | ITU-T G.694.1 compliant |
| Optical Connector | LC/PC Duplex |
| Transmission Distance | Up to 80 km (with appropriate amplifiers) |
| Protocol Support | STM-16/OC-48, G.709 OTN, 2.5GE |
| Installation | OSN subrack (OSN1800/6800/8800) |
| Power Consumption | < 20W |
| Operating Temperature | –5°C to +45°C |
| Storage Temperature | –40°C to +70°C |
| Humidity | 5%–95% RH, non-condensing |
| Compliance | CE, RoHS, NEBS Level 3, ISO9001 |
| Hot Swappable | Supported |
| Warranty | 1–3 Years Manufacturer Warranty |
TNF1LSCT75 Huawei Applications
- Metro WDM Networks — Efficient multiplexing and transmission of multiple 2.5G client signals
- Core DWDM Rings — Integration of legacy or low-speed services into modern transport layers
- Telecom Operators — Expansion of DWDM channel capacity using ITU-compliant fixed wavelengths
- Enterprise Long-Haul Links — Secure, high-stability optical transport over long distances
Customization & OEM Options
- Private Labeling — Branded with your logo and serial numbers
- Custom Wavelengths — Request for specific ITU channels (C21–C61)
- Network Configuration Support — Preloaded settings or template configs
- Compliance Documentation — Country-specific CE/FCC certification packages
- Compatibility Validation — Lab-tested for use in multi-vendor environments
Wholesale & Global Supply
- Huawei Original OEM — 100% genuine and factory-sealed
- Bulk Availability — Ideal for carrier-scale DWDM rollouts
- Global Shipping — Fast and reliable logistics with export support
- Volume Pricing — Discounts available for integrators and ISPs
- Technical Assistance — Engineering support for deployment and integration
Why Choose TNF1LSCT75 Huawei
- Enables seamless 2.5G client-to-DWDM wavelength conversion
- Supports long-haul transmission using the fixed 75th ITU-T wavelength
- Compatible with Huawei’s full DWDM ecosystem (OSN 1800/6800/8800)
- Easy deployment with hot-swappable design
- Cost-effective method to expand transport capacity without dark fiber
Contact us now to request a quote, datasheet, or bulk order details for the Huawei TNF1LSCT75 Wavelength Conversion Board — your reliable solution for next-generation DWDM transport.
