UPS5000-E-200 kVA Huawei Brand New Modular Design Supply
The UPS5000-E-200 kVA Huawei is a brand new, modular uninterruptible power supply (UPS) solution, purpose-built for large-scale data centers, telecom sites, enterprises, and industrial power-critical applications. With its modular architecture, it provides flexible scalability, high efficiency, and N+X redundancy, ensuring uninterrupted power protection and operational reliability. This 200 kVA model is part of Huawei’s advanced UPS5000-E series, designed to help reduce TCO, optimize space, and enhance power system resilience.
Key Features
-
Model: UPS5000-E-200 kVA
-
Condition: 100% Brand New, Original Huawei
-
Design: Fully Modular Architecture
-
Rated Capacity: 200 kVA / 200 kW (1.0 power factor)
-
Scalability: Expandable from 50 kVA up to 800 kVA in a single frame
-
High Efficiency: Up to 96% in double-conversion mode, 99% in ECO mode
-
Redundancy: Supports N+X module-level redundancy
-
Hot-Swappable Modules: Allows easy maintenance without shutdown
-
Battery Support: Compatible with both VRLA and Li-ion battery systems
-
Advanced Display: 10″ Color Touch LCD with multilingual support
-
Smart Management: Supports SNMP, Modbus, RS485, and dry contacts
Technical Specifications
| Parameter | Details |
|---|---|
| Model | UPS5000-E-200 kVA |
| Topology | Online Double-Conversion |
| Rated Power | 200 kVA / 200 kW |
| Input Voltage | 305 – 478 VAC (3-phase, line-to-line) |
| Input Frequency | 40–70 Hz |
| Output Voltage | 380/400/415 VAC (Configurable, 3-phase) |
| Output Power Factor | 1.0 (kVA = kW) |
| Efficiency (Online) | Up to 96% |
| Efficiency (ECO Mode) | Up to 99% |
| Battery Type | VRLA or Lithium-ion |
| Battery Configuration | External Battery Cabinets, Flexible Design |
| Display | 10-inch Color LCD Touchscreen |
| Communication Ports | SNMP, Modbus, RS485, Dry Contacts |
| Cooling | Intelligent Fan Cooling |
| Installation | Floor-standing, Front Access Design |
| Operating Temp. | 0°C to +40°C |
| Humidity Range | 0%–95% RH, non-condensing |
| Certifications | CE, IEC62040-1/2/3, RoHS, UL (region-dependent) |
| Warranty | 1–3 Years Manufacturer Warranty |
UPS5000-E-200 kVA Huawei Applications
-
Large Data Centers – Centralized UPS for server rooms and mission-critical racks
-
Telecom Facilities – Continuous power for switching centers and transmission sites
-
Financial Institutions – Stable power for banking systems and transaction servers
-
Government & Security – Power protection for secure and classified infrastructures
-
Industrial & Energy Plants – Reliable power for automation and sensitive equipment
Customization & OEM Options
-
Custom Branding – OEM logo, serial labels, and documentation available
-
Battery Cabinet Design – Configured with specified runtime and form factor
-
Integrated Monitoring Systems – SNMP/Modbus setup, pre-configured alerts
-
Power Distribution Customization – Factory-integrated PDU or bypass switches
-
Extended QA Testing – Burn-in testing and site simulation for critical applications
UPS5000-E-200 kVA Huawei Wholesale & Global Supply
-
Bulk Availability – Ideal for projects, infrastructure upgrades, and integrators
-
Direct Manufacturer Source – 100% Huawei Original, Factory Sealed
-
Secure Packaging – Palletized with anti-vibration and anti-static protection
-
Fast Delivery Worldwide – Certified for air and sea freight, export compliant
-
Volume Discounts – Tiered pricing for distributors and project procurement
-
Technical Support – Engineering assistance for setup, commissioning & training
-
After-Sales & Warranty – Full global warranty with optional extended service plans
Why Choose UPS5000-E-200 kVA Huawei Modular UPS
-
Scalable & Flexible — Add power modules as your business grows
-
High Efficiency — Reduce energy costs and cooling requirements
-
Redundancy Built In — N+X configuration ensures business continuity
-
Compact Footprint — Industry-leading power density in a small space
-
Smart Operations — Easy integration with data center infrastructure management (DCIM)
-
Trusted Huawei Quality — Backed by global R&D and deployment success
Contact Us Now for Pricing, Datasheets, and Lead Time
Enhance your power infrastructure with the Huawei UPS5000-E-200 kVA Modular UPS — a future-ready, high-performance, and intelligent backup power solution for enterprises that demand reliability, scalability, and energy savings.
