- Model Number:HK821
- Type:Fiber Optic Transceivers
- Place of Origin:Guangdong, China
- Brand Name:OEM
- Use:FTTX
- Warranty Time:3years
- Dimension:102mm(L) x 45mm(W) x45mm(H)
- Power consumption:6W
- WiFi:2.4G
-
- Supply Ability
- 5000 Piece/Pieces per Week
-
- Packaging Details
20pcs in 1 carton;
-
- Port
shenzhen/guangzhou/hongkong
- Lead time:Quantity(pieces)1 – 2000>2000Lead time (days)15To be negotiated
(1 10/100/1000M Port and 1 10/100M port)
2. 2.4G WIFI, 5dBi
3. CATV: support connect and disconnect from the OLT side.
4. one ON/OFF button
5. One Power input port
6. Compatible with ZTE, Huawei and other brands made in China.
Features
1. Comply fully with ITU-G.984.1/2/3/4 standard and G.987.3 protocol
2. Support bidirectional FEC and RS(255,239) FEC CODEC
3. Support 32 TCONT and 256 GEMPORT
4. Support AES128 decryption function of G.984 standard
5. Support SBA and DBA dynamically broadband allocation
6. Support the PLOAM function of G.984 standard
7. Support dying-gasp check and report
8. Support synchronous Ethernet
9. Support the rogue ONU alarm function
10. Support multiple VLAN function
11. Operation mode: SFU or HGU option
12. Support TR069, NAT, DMZ, DNS features
13. Support IPV, PPPOE, DHCP, and Static IP configuration for WAN interface
14. Support IP, MAC Filtering, Firewall functionality in routed mode
15. Good interworking with the OLT from different manufacturers , such as Huawei, ZTE, cortina , etc.
|
Type
|
Fiber Optic Transceivers
|
|
Single-Mode Fiber
|
Tx 1310nm,Rx 1490nm
|
|
No. of Fiber
|
1
|
|
Use
|
FTTX
|
|
Power Input
|
12V 1.5A
|
|
Warranty Time
|
3years
|
|
Dimension
|
102mm(L) x 45mm(W) x45mm(H)
|
|
Power consumption
|
6W
|
|
Application
|
FTTH FTTB FTTX Network
|
