ZTE GM219-S Overview:
The ZTE GM219-S is a ZTE or MTK Chipset chipset GPON or XPON ONU, it support both GPON and EPON OLTs. It has 1GE 3FE 1POTS 1USB 2.4G single band WIFI with two 2Dbi antennas. It’s quite similar with the polular selling ONTs such as Huawei HG8546M, Huawei EG8141A5, ZTE F660 V8.0 V6.0, but the price is much lower, it’s a quite cost saving choice for customers.
ZTE GM219-S Specifications:
| Brand | China Mobile OEM |
| Model | GM219-S |
| Dimensions (L x W x H) | 30 mm x 152 mm x 105 mm |
| (without external antenna and pads) | |
| Weight | < 180 g |
| Operating Temperature | 0°C to +40°C |
| Operating Humidity | 5% RH to 95% RH (non-condensing) |
| Power Adapter Input | 100V to 240V AC, 50/60 Hz |
| System Power Supply | 11V to 14V DC, 1.5A |
| Static Power Consumption | 3.1W |
| Maximum Power Consumption | 7.15W |
| NNI | GPON EPON XPON |
| UNI | 1 POTS + 1 GE + 3 FE + 2.4G Wi-Fi |
| Optical Connector | SC/APC, SC/UPC |
| Indicators | POWER/PON/LOS/LAN/TEL/WLAN/WPS |
Model Number:gm219-s
- Type: ONU
- Place of Origin: Guangdong, China
- Brand Name: Huawei
- Use: FTTH
- Warranty Time:1 year
- Network: Wired LAN, wifi
- Supply Ability1000 Piece/Pieces per Week
- PortShenzhen
- Picture Example:
- Lead time:Quantity(pieces)1 – 2000>2000Lead time (days)15To be negotiated
