ZTE GPON OLT Class C++ High Quality SFP Optical Transceiver
The ZTE GPON OLT Class C++ SFP Optical Transceiver is a high-quality, hot-swappable optical module designed specifically for ZTE OLT platforms in GPON (Gigabit Passive Optical Network) deployments. Engineered for long-reach up to 40 km, this Class C++ SFP provides enhanced optical budget and is ideal for high-density FTTH (Fiber-to-the-Home) and FTTx applications.
Key Features
- Model: ZTE GPON OLT SFP (Class C++)
- Form Factor: SFP (Small Form-Factor Pluggable)
- Technology: GPON OLT Transceiver Module
- Class: C++ (High Optical Budget)
- Wavelengths: TX 1490 nm / RX 1310 nm
- Transmission Distance: Up to 40 km
- Connector Type: SC/UPC simplex
- Compatibility: Fully compatible with ZTE OLT series (C300, C320, C350, etc.)
- Hot-Pluggable: Yes – supports online insertion and removal
Technical Specifications
| Specification | Details |
|---|---|
| Transmitter Type | DFB Laser (1490 nm) |
| Receiver Type | APD (Avalanche Photodiode, 1310 nm) |
| Optical Output Power | +3 dBm to +7 dBm |
| Receiver Sensitivity | ≤ -32 dBm (typical) |
| Optical Budget | ≥ 35 dB (Class C++) |
| Transmission Range | 2 km to 40 km |
| Data Rate | 2.488 Gbps downstream / 1.244 Gbps upstream |
| Connector | SC/UPC Simplex |
| Power Supply | 3.3V |
| Operating Temp. | -10°C to +85°C |
| Compliance | ITU-T G.984.2, SFF-8472, RoHS |
| Hot Swap Support | Yes |
| Diagnostic Monitoring | DDM/DOM (Digital Optical Monitoring) Supported |
ZTE GPON OLT Class C++ Applications
- FTTH Deployments – Core component in GPON-based fiber broadband networks
- ZTE OLT Systems – Fully compatible with C300, C320, C350, and similar models
- Service Provider Networks – Scalable solution for high-density subscriber access
- Long-Distance PON Solutions – Perfect for rural or sparsely populated deployments
- Municipal and Utility Networks – Stable high-speed access for public services
Customization & OEM Options
- Private Labeling – Custom logo and part number on SFP module
- Firmware Matching – Pre-loaded ZTE-compatible firmware for zero config
- Serial Number Control – Vendor-specific SN for managed network integration
- Packaging Customization – Retail blister pack or neutral industrial packaging
- Custom Reach Options – Tailored models for 10 km, 20 km, or 40 km GPON reach
Wholesale & Global Supply Chain
- High Availability Stock – Bulk inventory ready for immediate dispatch
- Competitive Bulk Pricing – Discounts for telecom operators and integrators
- Reliable Shipping – Secure packaging for global logistics (air/sea/DHL/FedEx)
- Warranty & Support – 12–36 month warranty with full technical support
- Compatibility Assurance – Rigorously tested with ZTE GPON OLTs
Why Choose ZTE GPON OLT Class C++
High Optical Budget – Up to 35 dB for reliable long-distance transmission
Carrier-Grade Reliability – Built to telecom standards for 24/7 operation
Flexible Compatibility – Designed specifically for ZTE GPON infrastructure
Hot-Pluggable Convenience – Minimizes service downtime during maintenance
Smart Diagnostics – DDM/DOM for live signal monitoring and troubleshooting
Get a Quote Today for Samples or Bulk Orders
Whether you’re rolling out new fiber networks or upgrading existing OLT systems, the ZTE GPON OLT Class C++ SFP offers the performance, reliability, and scalability needed. Contact us now for wholesale pricing, technical datasheets, or OEM requests tailored to your project.
