48-FC Fiber ODF Rack Mount Distribution Box – Brand New | High-Density Termination Unit
Product Overview
The 48-FC Fiber ODF Rack Mount Distribution Box is a high-capacity optical distribution frame designed to support up to 48 FC simplex connections in a standard 19-inch rack mount setup. Built from durable cold-rolled steel with a professional powder-coated finish, this enclosure provides secure termination, protection, and management of fiber optic cables in telecom, data center, and enterprise environments.
Ideal for FTTH deployments, telecom headends, LAN backbones, and network test environments, this brand-new distribution box offers clean cable routing, adapter mounting, and optional splice tray integration, ensuring neat and reliable fiber connectivity.
Key Features of 48-FC Fiber ODF Rack
-
✅ Fiber Capacity: 48 fibers with FC simplex adapter compatibility
-
✅ Mounting Standard: 19-inch rack mountable (1U or 2U height options)
-
✅ Material: Cold-rolled steel with anti-corrosion powder coating
-
✅ Color Options: Standard light gray (RAL 7035) or custom (e.g., black)
-
✅ Front Panel: Pre-cut 48-port FC simplex adapter layout
-
✅ Cable Management: Rear and side entry ports with strain relief
-
✅ Condition: 100% Brand New – Sealed Packaging
-
✅ Standards: RoHS, CE, ISO9001 Compliant
48-FC Fiber ODF Rack Technical Specifications
| Specification | Detail |
|---|---|
| Adapter Type | FC simplex (UPC or APC) |
| Total Capacity | 48 fibers (48 FC connectors) |
| Enclosure Type | Rack Mount (19-inch standard) |
| Dimensions (Standard 1U) | 430mm × 300mm × 44mm |
| Material | Cold-rolled steel |
| Surface Finish | Powder-coated (Anti-static & corrosion-resistant) |
| Cable Entry Ports | Rear and/or side entry with cable glands |
| Splice Tray Support | Optional (1–2 trays, 12/24 fibers each) |
| Operating Temperature | -40°C to +60°C |
| Storage Temperature | -45°C to +85°C |
| Protection Level | IP20 (for indoor rack use) |
48-FC Fiber ODF Rack Applications
-
🌐 FTTH & FTTx Optical Access Networks
-
📡 Telecommunication Rooms & MDF/IDF Closets
-
🏢 Enterprise Structured Cabling Systems
-
☁️ Data Centers and Server Racks
-
🔬 Optical Testing, Monitoring, and Patch Systems
Customization Options
We offer flexible OEM/ODM and project-specific customization:
-
🔧 Adapter Options: FC/UPC or FC/APC (green or blue color caps)
-
🔧 Pigtail Preloading: Optional FC pigtails, singlemode or multimode
-
🔧 Branding: Custom logo printing, laser engraving, or label tagging
-
🔧 Tray Configuration: Sliding or fixed type, with or without splice trays
-
🔧 Color Matching: Any RAL code or corporate color scheme
-
🔧 Pre-Bundled Kits: Complete with adapters, splice trays, and pigtails
Let us tailor this unit for your specific deployment or reseller needs.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | 48-FC Fiber ODF |
| Dimension (L × W × H) | 483 × 255 × 133 mm |
| Weight | 6.8 kg |
| Air Pressure | 70 KPa ~ 106 KPa |
| Relative Humidity | ≤ 95% (at +40°C) |
| Operating Temperature | -40°C ~ +60°C |
| Included | 1 unit 48 Fiber Distribution Box 4 units of 12-Fiber Integration Tray Fully equipped FC adapters |
| Port Capacity | 48 Ports |
Additional Information
| Attribute | Value |
|---|---|
| Weight | 0.0 kg (placeholder) |
| Dimensions | 0.0 × 0.0 × 0.0 cm (placeholder) |
| Connector Type | FC |
| Port Count | 48 |
Wholesale & Bulk Supply Support
Trusted by ISPs, network installers, and telecom distributors globally:
-
📦 Bulk Pricing & Volume Discounts
-
📦 MOQ Flexibility for Projects & Inventory Restocks
-
📦 Fast Manufacturing & Global Delivery Options
-
📦 Custom Labeling & Packaging for OEM Sales
-
📦 Documentation: CE, RoHS, Test Reports, Certificate of Origin (COO)
Why Choose Our 48-FC Rack Mount ODF?
-
✔️ Secure and Organized FC Termination
-
✔️ Industrial-Grade Build for Long-Term Use
-
✔️ Full Rack Compatibility with Easy Access Paneling
-
✔️ Supports Neat Cable Routing and High-Density Installations
-
✔️ Certified for Global Telecom & Data Infrastructure
Order Now
Streamline your fiber deployment with the 48-FC Fiber ODF Rack Mount Distribution Box — the ideal solution for professional-grade fiber organization, splicing, and termination. Now available with OEM branding, adapter options, and wholesale pricing.
